889PF4DCH
BRAND: NHP

AB 889P Cordset Connector IDC Terminal Chamber 4Pin 22 to 26AWG Pico Female


$47.00 List price: $62.40
+

Product Name/Title: AB 889P Cordset Connector IDC Terminal Chamber 4Pin 22 to 26AWG Pico Female

Brand: NHP

SKU: 889PF4DCH

Alternatively Known As: 4Pin IDC Connector, Pico Female Connector, Circular Connector

Technical Specifications
  • Rated Current: 3 A
  • Rated Voltage: 22 V
  • Number of Poles: 4
  • Degree of Protection: IP67
  • Type of Plug: Female (bus)
  • Material Housing: Other
  • Coating Housing: Nickel-plated
  • Material of Contact Surface: Gold
  • Mounting Method: Freely positionable
  • Operating Temperature: -25 to 85 °C
  • Dimensions (H x L x W): 20mm x 50mm x 30mm
  • Weight: 0.2 kg
Key Features
  • IP67 rated for protection against dust and water ingress.
  • Nickel-plated housing for enhanced durability.
  • Gold contact surface for improved conductivity.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Suitable for various industrial applications requiring reliable connections.
  • Commercial: Ideal for use in commercial electrical installations.
Standards & Compliance
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
  • Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The AB 889P Cordset Connector IDC Terminal Chamber 4Pin 22 to 26AWG Pico Female is available now for immediate purchase. Ideal for industrial and commercial applications.

Non-Returnable & Non-Cancellable

889PF4DCH-AU-PVC-Cable-IDC-Connector-Datasheet.pdf (889PF4DCH-AU-PVC-Cable-IDC-Connector-Datasheet.pdf, 236 Kb) [Download]
