100FA04
BRAND: NHP

Allen-Bradley 100C Auxiliary Contact with 4NC Contacts Front Mount


$89.50 List price: $118.80
+

Product Name/Title: Allen-Bradley 100C Auxiliary Contact with 4NC Contacts Front Mount

Brand: NHP

SKU: 100FA04

Alternatively Known As: Auxiliary Contact Block, 100C Contact, NHP Auxiliary Contact

Technical Specifications
  • Number of Contacts: 4 NC
  • Rated Insulation Voltage: 690 V
  • Rated Operation Current (AC 15) at 24 V: 6 A
  • Rated Operation Current (AC 15) at 120 V: 6 A
  • Rated Operation Current (AC 15) at 240 V: 5 A
  • Rated Operation Current (AC 15) at 400 V: 3 A
  • Rated Operation Current (DC 12-24 V): 12 A
  • Rated Operation Current (DC 12-110 V): 3.5 A
  • Rated Operation Current (DC 12-220 V): 0.55 A
  • Rated Operation Current (DC 13-24 V): 5 A
  • Rated Operation Current (DC 13-110 V): 1.2 A
  • Rated Operation Current (DC 13-220 V): 0.6 A
  • Min Contact Rating Current: 5 mA
  • Min Contact Rating Voltage: 17 V
  • Rated Operation Current (AC 15) at 230 V: 5.5 A
  • Dimensions (H x L x W): 50mm x 100mm x 100mm
  • Weight: 0.5 kg
Key Features
  • 4 Normally Closed (NC) contacts for reliable operation.
  • Rated insulation voltage of 690 V for high voltage applications.
  • Top mounting method for easy installation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Control panels, machinery, and automation systems
  • Commercial: Electrical installations requiring auxiliary contacts
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
  • Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 100C Auxiliary Contact with 4NC Contacts Front Mount is available now for immediate purchase. Ideal for industrial and commercial electrical applications.

Non-Returnable & Non-Cancellable

100FA04-AU-Contactor-Auxiliary-Contact-Datasheet.pdf (100FA04-AU-Contactor-Auxiliary-Contact-Datasheet.pdf, 229 Kb) [Download]
