Allen-Bradley 140G MCCB J Frame Trip Unit 4P 100A Electronic LSIG

SKU: 140GJTI4D10

BRAND: NHP

Allen-Bradley 140G MCCB J Frame Trip Unit 4P 100A Electronic LSIG

$1,114.50 List price: $1,480.00

+ −

30 Days Return Delivery Options

Description
Attachments

Product Name/Title: Allen-Bradley 140G MCCB J Frame Trip Unit 4P 100A Electronic LSIG

Brand: NHP

SKU: 140GJTI4D10

Alternatively Known As: MCCB, Molded Case Circuit Breaker, Circuit Breaker 100A

Technical Specifications

Rated Current: 100 A
Number of Poles: 4
Type of Protection: Electronic release
Trip Curve: LSIG
Frame Size Rating: 250 A
Long Time Overload Protection Adjustment: 40-100 A
Instantaneous Protection Adjustment: 100-1000 A
Rated Frequency: 50-60 Hz
Rated Insulation Voltage: 1000 V
Short Time Protection Adjustment: 100-1000 A
Rated Impulse Withstand Voltage: 8 kV
Maximum Operating Temperature: 75 °C
Storage Temperature: -40-80 °C
Max Altitude Before Derating: 2000 m
Dimensions (H x L x W): 200mm x 100mm x 140mm
Weight: 2.5 kg

Key Features

Electronic release for precise trip settings.
LSIG trip curve for comprehensive protection.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Power distribution and protection in commercial and industrial settings
Residential: Electrical panels requiring circuit protection

Standards & Compliance

Complies with AS/NZS 3000 for electrical installation standards.

Environmental Benefits

Designed to operate efficiently in a wide range of temperatures, reducing energy waste.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 140G MCCB J Frame Trip Unit 4P 100A Electronic LSIG is available now for immediate purchase. Ideal for industrial and residential electrical protection.

Non-Returnable & Non-Cancellable

140GJTI4D10-AU-140G-MCCB-Trip-Unit-Datasheet.pdf (140GJTI4D10-AU-140G-MCCB-Trip-Unit-Datasheet.pdf, 245 Kb) [Download]
