140MTD9NC32
BRAND: NHP

Allen-Bradley 140MT Motor Circuit Protector 32A


$539.50 List price: $716.40
+

Product Name/Title: Allen-Bradley 140MT Motor Circuit Protector 32A

Brand: NHP

SKU: 140MTD9NC32

Alternatively Known As: Motor Circuit Breaker, Motor Protection Circuit Breaker, 140MTD9NC32

Technical Specifications
  • Rated permanent current: 32 A
  • Max rated operation voltage: 690 V
  • Rated operation power at AC 3, 400 V: 15 kW
  • Number of poles: 3
  • Max tightening torque: 2.5 Nm
  • Dimensions (H x L x W): 96.3mm x 93.7mm x 45mm
  • Weight: 0.41 kg
Key Features
  • Rated permanent current: 32 A
  • Magnetic switch-off technique
  • Rated short-circuit breaking capacity: 50 kA
  • Turn handle control element
  • IP2X degree of protection
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Motor protection in manufacturing and processing plants
  • Commercial: Equipment protection in commercial facilities
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
  • Enhances safety and reliability in electrical systems, reducing the risk of equipment failure.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 140MT Motor Circuit Protector 32A is available now for immediate purchase, ideal for industrial and commercial applications.

140MTD9NC32-AU-Motor-Circuit-Protector-Datasheet.pdf (140MTD9NC32-AU-Motor-Circuit-Protector-Datasheet.pdf, 220 Kb) [Download]
