Allen-Bradley 700-HL Solid State Interface Relay 10A 2CO DPDT 24VAC DC Coil Standard Silver Contacts
The Allen-Bradley 700-HL Solid State Interface Relay offers reliable switching capabilities with a nominal current of 10A and dual changeover contacts, ideal for various industrial and commercial applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley 700-HL Solid State Interface Relay 10A 2CO DPDT 24VAC DC Coil Standard Silver Contacts
Brand: NHP
SKU: 700HLT12U24
Alternatively Known As: Solid State Relay, Interface Relay, DPDT Relay
Technical Specifications
- Nominal Current: 10 A
- Nominal Voltage AC: 250 V
- Rated Switching Power at AC-1: 2500 VA
- Rated Switching Power at AC-15 (230 V): 690 VA
- Breaking Capacity at DC-1 (30 V): 10 A
- Voltage Type for Actuating: AC/DC
- Control Supply Voltage at AC 50 Hz: 24 V
- Control Supply Voltage at DC: 24 V
- Control Supply Voltage at AC 60 Hz: 24 V
- Electrical Life at Un in Service: 100,000 cycles
- Mechanical Life Service Cycles: 10,000,000 cycles
- Degree of Protection: IP20
- Operating Temperature: -40 to 55 °C
- Material Contact: Silver tin-oxide
- Dimensions (H x L x W): 88mm x 76mm x 62mm
- Weight: 0.5 kg
Key Features
- 10A nominal current with 2 changeover contacts.
- LED indication for operational status.
- Suitable for plug-in socket mounting.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Long electrical life reduces waste and maintenance frequency.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley 700-HL Solid State Interface Relay is available now for immediate purchase. Ideal for industrial automation and control applications.
Non-Returnable & Non-Cancellable
