Allen-Bradley 700S-CF Safety Control Relay 240VAC Coil 8Pole 4NO 4NC Contact Auxiliary

BRAND: NHP
SKU: 700SCF440TC
$237.50 List price: $315.30
+
The Allen-Bradley 700S-CF Safety Control Relay is designed for reliable control in safety applications, featuring a robust 8-pole configuration with 4 normally open and 4 normally closed contacts.

Product Name/Title: Allen-Bradley 700S-CF Safety Control Relay 240VAC Coil 8Pole 4NO 4NC Contact Auxiliary

Brand: NHP

SKU: 700SCF440TC

Alternatively Known As: Safety Relay, Control Relay, 700S-CF Relay

Technical Specifications
  • Number of Auxiliary Contacts (NO): 4
  • Number of Auxiliary Contacts (NC): 4
  • Rated Operation Current (Ie) at 400V: 20 A
  • Rated Operation Current (Ie) at 400V (2): 10 A
  • Max Rated Operation Voltage (Ue) AC: 690 V
  • Voltage Type for Actuating: AC
  • Control Supply Voltage (Us) at AC 50 Hz: 240 V
  • Power Consumption AC Coil Pickup: 75 VA
  • Power Consumption AC Coil Hold-in: 9.5 VA
  • Control Supply Voltage (Us) at AC 60 Hz: 277 V
  • Mounting Method: DIN-rail/screw
  • Connection Type Auxiliary Circuit: Screw connection
  • Dimensions (H x L x W): 81mm x 119.5mm x 45mm
  • Weight: 0.45 kg
Key Features
  • 8-pole configuration with 4 normally open and 4 normally closed contacts.
  • Rated for 240VAC coil operation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Automation systems, machinery control
  • Commercial: Safety systems in buildings and facilities
Standards & Compliance
  • Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
  • Enhances safety in industrial and commercial environments, reducing the risk of accidents.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Allen-Bradley 700S-CF Safety Control Relay is available now for immediate purchase. Ideal for industrial automation and safety systems.

Non-Returnable & Non-Cancellable

700SCF440TC-AU-Safety-Control-Relay-Datasheet.pdf (700SCF440TC-AU-Safety-Control-Relay-Datasheet.pdf, 282 Kb) [Download]
