Product Name/Title: Allen-Bradley Flex IO 2Ai 2AO Current Voltage Isolated Module
Brand: NHP
SKU: 1794IF2XOF2I
Alternatively Known As: Flex IO Analogue Module, Allen-Bradley 1794IF2XOF2I
Technical Specifications
- Type of Voltage Input: DC
- Analogue Input Voltage: Yes
- Resolution of the Analogue Inputs: 16 Bit
- Analogue Input Signal Configurable: Yes
- Analogue Output Voltage: Yes
- Resolution of the Analogue Outputs: 16 Bit
- Analogue Output Signal Configurable: Yes
- Supply Voltage DC: 24-24 V
- Analogue Inputs Configurable: Yes
- Analogue Outputs Configurable: Yes
- Analogue Input Current: Yes
- Analogue Output Current: Yes
- Suitable for Safety Functions: No
- Number of Analogue Inputs: 2
- Number of Analogue Outputs: 2
- Operating Temperature: 0-55 °C
- Storage Temperature: -40-85 °C
- Max Ambient Humidity Non-Condensing: 95 %
- Dimensions (H x L x W): 45.7mm x 53.3mm x 94mm
- Weight: 0.5 kg
Key Features
- 16-bit resolution for both analogue inputs and outputs.
- Configurable analogue input and output signals.
- Supports DC voltage input.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial automation systems
- Process control applications
- Data acquisition systems
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Designed for high performance in various environmental conditions, reducing the need for frequent replacements.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley Flex IO 2Ai 2AO Current Voltage Isolated Module is available now for immediate purchase. Ideal for industrial automation and process control applications.
