Auxiliary Contact Block 3NO 1NC | 690V Insulation | Top Mount by NHP
Auxiliary contact block with 3NO and 1NC contacts—ideal for industrial and commercial control systems. Built for reliability, with 690V insulation and top mounting for easy installation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: S+S CS8 Auxiliary Contact with 3NO Contacts and 1NC Contact
Brand: NHP
SKU: CS8P31Z
Alternatively Known As: Auxiliary Contact Block, Control Relay Contact
Technical Specifications
- Number of NO contacts: 3
- Number of NC contacts: 1
- Rated insulation voltage: 690 V
- Rated operation current at 40°C: 10 A
- Rated operation current at AC 15, 24 V: 3 A
- Rated operation current at AC 15, 120 V: 3 A
- Rated operation current at AC 15, 240 V: 2 A
- Rated operation current at AC 15, 400 V: 1.2 A
- Rated operation current at DC 13, 24 V: 2.3 A
- Rated operation current at DC 13, 110 V: 0.55 A
- Rated operation current at DC 13, 220 V: 0.27 A
- Minimum contact rating current: 2 mA
- Minimum contact rating voltage: 15 V
- Rated operation current at AC 15, 230 V: 2 A
- Mounting method: Top mounting
- Dimensions (H x L x W): 100mm x 75mm x 50mm
- Weight: 0.5 kg
Key Features
- 3 Normally Open (NO) contacts and 1 Normally Closed (NC) contact.
- Rated insulation voltage of 690 V.
- Top mounting method for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control systems, automation equipment
- Commercial: Electrical panels, machinery control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS8 Auxiliary Contact with 3NO and 1NC Contacts is available now for immediate purchase. Ideal for industrial and commercial control applications.
