Product Name/Title: Cirprotec Final Diverters SPD Analogue 24V 7 Wires
Brand: NHP
SKU: CPTDIN24V8
Alternatively Known As: Surge Protection Device, Final Diverter, SPD for Data Networks
Technical Specifications
- Nominal Voltage AC: 24 V
- Max Continuous Voltage AC: 16 V
- Nominal Discharge Surge Current (8/20): 5 kA
- Max Discharge Surge Current (8/20): 10 kA
- Lightning Impulse Current (10/350 µs): 10 kA
- Voltage Protection Level (Core-Core): 67 V
- Voltage Protection Level (Core-Earth): 67 V
- Voltage Protection Level (Core-Signal Ground): 39 V
- Frequency: 3000000 MHz
- Number of Protected Wires: Other
- Mounting Method: DIN rail (top hat rail) 35 mm
- Degree of Protection: IP20
- Max Conductor Cross Section: 2.5 mm²
- Dimensions (H x L x W): 90mm x 60mm x 52.5mm
- Weight: 0.11 kg
Key Features
- Surge Protection Device designed for final stage protection.
- IP20 rated for indoor use.
- DIN rail mounting for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Protection of electrical installations and equipment from surges.
- Commercial: Suitable for data networks and MCR technology.
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Protects sensitive equipment from voltage spikes, reducing waste and prolonging equipment life.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Cirprotec Final Diverters SPD Analogue 24V 7 Wires is available now for immediate purchase. Ideal for industrial and commercial applications requiring surge protection.
Non-Returnable & Non-Cancellable
