Product Name/Title: Cirprotec Final Diverters SPD RS485 1 Pair
Brand: NHP
SKU: CPTDIN4852C
Alternatively Known As: Surge Protection Device, SPD for RS485, Final Diverter
Technical Specifications
- Nominal Voltage AC: 48 V
- Max Continuous Voltage AC: 180 V
- Nominal Discharge Surge Current (8/20): 5 kA
- Max Discharge Surge Current (8/20): 10 kA
- Lightning Impulse Current (10/350 µs): 10 kA
- Voltage Protection Level Core-Earth: 20 V
- Frequency: 5000000 MHz
- Number of Protected Wires: Other
- Mounting Method: DIN rail (top hat rail) 35 mm
- Degree of Protection: IP20
- Max Conductor Cross Section: 2.5 mm²
- Dimensions (H x L x W): 90mm x 70mm x 17.5mm
- Weight: 0.06 kg
Key Features
- Designed for surge protection in data networks.
- DIN rail mounting for easy installation.
- IP20 rated for indoor use.
Professional Installation Requirements
- Professional installation is recommended for optimal performance and safety.
Applications
- Surge protection for data networks
- Industrial applications
- Telecommunications
Standards & Compliance
- Complies with relevant Australian standards for surge protection devices.
Environmental Benefits
- Helps protect sensitive electronic equipment from voltage spikes.
Warranty Information
Standard warranty applies.
Available Now
The Cirprotec Final Diverters SPD RS485 1 Pair is available now for immediate purchase. Ideal for surge protection in data networks.
Non-Returnable & Non-Cancellable
