Product Name/Title: Finder 34 Series Slim Printed Circuit Board Relay 6A 1 Changeover 6V DC Coil
Brand: NHP
SKU: 345160VDC
Alternatively Known As: PCB Relay, Switching Relay, Finder Relay
Technical Specifications
- Nominal Current: 6 A
- Nominal Voltage AC: 250 V
- Max Rated Operation Voltage (UE AC): 400 V
- Rated Switching Power at AC 1: 1500 VA
- Rated Switching Power at AC 15 (230 V): 300 VA
- Breaking Capacity at DC 1 (30 V): 6 A
- Breaking Capacity at DC 1 (110 V): 0.2 A
- Control Supply Voltage (US) at DC: 60 V
- Electrical Life at UN in Service: 60000 cycles
- Mechanical Life Service Cycles: 10000 cycles
- Operating Temperature: -40 to 85 °C
- Dimensions (H x L x W): 28mm x 15mm x 5mm
- Weight: 0.1 kg
Key Features
- Compact design suitable for PCB mounting.
- Mono stable operation with a single changeover contact.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
- General: Any application requiring reliable switching
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Energy-efficient operation reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Finder 34 Series Slim Printed Circuit Board Relay is available now for immediate purchase, ideal for various industrial and commercial applications.
