BRAND: NHP

Mersen FR Cylindrical Fuse 22 x 58mm 690V AC 40A


$17.40 List price: $23.10
+

Product Name/Title: Mersen FR Cylindrical Fuse 22 x 58mm 690V AC 40A

Brand: NHP

SKU: FR22GG69V40

Alternatively Known As: Cylindrical Fuse, Fuse 22x58mm, 40A Fuse, Mersen Fuse

Technical Specifications
  • Utilization Category: gL/gG (cable protection/equipment protection)
  • Breaking Capacity AC: 120 kA
  • Breaking Capacity DC: 100 kA
  • Voltage Type: AC/DC
  • Rated Current: 40 A
  • Rated Voltage AC: 690 V
  • Rated Voltage DC: 250 V
  • Power Loss at Rated Current: 4.3 W
  • Model: Ceramic fuse
  • Dimensions (H x L x W): 58mm x 22mm x 22mm
  • Weight: 0.1 kg
Key Features
  • Cylindrical design for easy installation.
  • High breaking capacity of 120 kA for AC.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Electrical distribution systems
  • Industrial equipment protection
  • Commercial electrical installations
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installation standards.
Environmental Benefits
  • Reduces the risk of electrical fires by providing effective circuit protection.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Mersen FR Cylindrical Fuse 22 x 58mm 690V AC 40A is available now for immediate purchase. Ideal for electrical distribution and industrial applications.

Non-Returnable & Non-Cancellable

FR22GG69V40-AU-Cylindrical-Fuse-Datasheet.pdf (FR22GG69V40-AU-Cylindrical-Fuse-Datasheet.pdf, 252 Kb) [Download]
