BRAND: NHP

Mersen FR Cylindrical Fuse 22 x 58mm 690V AC 80A


$18.00 List price: $24.00
+

Product Name/Title: Mersen FR Cylindrical Fuse 22 x 58mm 690V AC 80A

Brand: NHP

SKU: FR22GG69V80

Alternatively Known As: Cylindrical Fuse, Fuse 22x58mm, 80A Fuse

Technical Specifications
  • Utilization Category: gL/gG (cable protection/equipment protection)
  • Breaking Capacity AC: 120 kA
  • Breaking Capacity DC: 100 kA
  • Voltage Type: AC/DC
  • Rated Current: 80 A
  • Rated Voltage AC: 690 V
  • Rated Voltage DC: 250 V
  • Power Loss at Rated Current: 7.4 W
  • Model: Ceramic fuse
  • Dimensions (H x L x W): 58mm x 22mm x 22mm
  • Weight: 0.1 kg
Key Features
  • Cylindrical design for easy installation.
  • High breaking capacity of 120 kA for AC applications.
  • Rated for 80 A current and 690 V AC voltage.
Professional Installation Requirements
  • Installation by a qualified electrician is recommended for safety and compliance.
Applications
  • Electrical distribution systems
  • Industrial equipment protection
  • Commercial electrical installations
Standards & Compliance
  • Complies with relevant Australian standards for electrical safety.
Environmental Benefits
  • Designed for efficient power management and reduced energy loss.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Mersen FR Cylindrical Fuse 22 x 58mm 690V AC 80A is available now for immediate purchase. Ideal for electrical distribution and protection applications.

FR22GG69V80-AU-Cylindrical-Fuse-Datasheet.pdf (FR22GG69V80-AU-Cylindrical-Fuse-Datasheet.pdf, 252 Kb) [Download]
