IP69214/S/WG

Monarch IP 1800Hx600Wx400D IP66 SS N4 VW Glass


$11,119.40 List price: $13,976.00

Free pick up (over 25 kg)
For delivery quote message

Product Name/Title: Monarch IP 1800Hx600Wx400D IP66 SS N4 VW Glass

Brand: B&R Enclosures

SKU: IP69214/S/WG

Alternatively Known As: Monarch IP Enclosure, Stainless Steel Viewing Window Enclosure, IP66 Enclosure

Technical Specifications
  • Material: 1.2/1.5mm thick 316 stainless steel
  • Gland plate: 1.5mm 316 stainless steel (brass option available)
  • Polyurethane gasket (foamed in place)
  • ASSDA approved N4 surface finish
  • Region D wind rated to AS1170.2-2002
  • Dimensions (H x L x W): 600mm x 600mm x 1800mm
  • Weight: 50 kg
Key Features
  • IP66 protection rating
  • Glass Viewing Window
  • 3 point locking on models of 600mm high and above
  • Stainless steel hinges and hinge pins for easy door opening
Professional Installation Requirements
  • Professional installation is recommended for optimal performance and safety.
Applications
  • Industrial: Small motor control applications
  • Commercial: Lighting and CT metering
  • General: Small switchboards
Standards & Compliance
  • Complies with AS/NZS 61439 for low-voltage switchgear and controlgear assemblies.
Environmental Benefits
  • Durable stainless steel construction reduces the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Monarch IP – Viewing Window (SS) is available now for immediate purchase. Ideal for industrial and commercial applications requiring robust and flexible enclosures.
