Product Name/Title: Monarch IP 2007Hx407Wx502D IP66 Al 7035 VW Glass
Brand: B&R Enclosures
SKU: IP77135/A/WG
Alternatively Known As: Monarch IP Viewing Window, IP66 Viewing Window, Aluminium Viewing Window
- Body: Aluminium
- Body thickness: 2.5mm
- Polyurethane gasket: formed in place
- Powdercoated light grey RAL7035 or Ripple Orange
- 5.4mm thick glass viewing window
- C rail mountings
- Gland plate: fitted internally or externally
- Lockable L handles: above 1600mm high
- 3-point locking: 600mm high and above
- Removable back: 400mm deep and above
- Dimensions (H x L x W): 600mm x 407mm x 2007mm
- Weight: 5 kg
- IP66 protection rating
- Vertical body and door rails
- Earth strap kit comes as standard
- Reversible doors
- Multiple mounting options
- Wide range of accessories
- Glass Viewing Window
- Region D wind rated
- Professional installation is recommended to ensure compliance with safety standards.
- Small motor control applications
- Lighting
- CT metering
- Small switchboards
- Complies with AS/NZS 61439 for low-voltage switchgear and controlgear assemblies.
- Region D wind rated to AS1170.2-2002 for structural design actions.
- Durable materials reduce the need for frequent replacements, minimizing waste.
1 year warranty against manufacturing defects.
The Monarch IP – Viewing Window (AL) is available now for immediate purchase, ideal for various electrical applications.
