ARCLORS5I3O24VDCPLS
BRAND: NHP

NHP Arclogix Optical RS Arc Detection Relay 5I and 3O DIN Mount


$5,874.60 List price: $7,800.70
+

Product Name/Title: NHP Arclogix Optical RS Arc Detection Relay 5I and 3O DIN Mount

Brand: NHP

SKU: ARCLORS5I3O24VDCPLS

Alternatively Known As: Arc Detection Relay, Optical Arc Relay, DIN Mount Arc Relay

Technical Specifications
  • Voltage Type for Actuating: AC/DC
  • Rated Control Supply Voltage (US) at AC 50 Hz: 19-65 V
  • Rated Control Supply Voltage (US) at DC: 19-85 V
  • Max Flash to Trip Duration: 7 ms
  • Number of Inputs: 5
  • Number of Contacts as Normally Open Contact: 3
  • Operating Temperature: -10-55 °C
  • Storage Temperature: -25-70 °C
  • Dimensions (H x L x W): 65mm x 124mm x 100mm
  • Weight: 0.5 kg
Key Features
  • Optical arc detection technology for enhanced safety.
  • DIN rail mounting for easy installation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Arc detection in electrical systems
  • Commercial: Safety monitoring in electrical installations
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installation safety.
Environmental Benefits
  • Improves safety in electrical installations, reducing the risk of fire hazards.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The NHP Arclogix Optical RS Arc Detection Relay 5I and 3O DIN Mount is available now for immediate purchase. Ideal for industrial and commercial applications requiring advanced arc detection.

ARCLORS5I3O24VDCPLS-AU-Arclogix-Relay-Datasheet.pdf (ARCLORS5I3O24VDCPLS-AU-Arclogix-Relay-Datasheet.pdf, 376 Kb) [Download]
