Product Name/Title: NHP DIN-T Main Switch 2Pole 80A
Brand: NHP
SKU: DINTMS802
Alternatively Known As: NHP 80A Main Switch, DIN Rail Main Switch, 2 Pole Circuit Breaker
Technical Specifications
- Rated Current: 80 A
- Number of Poles: 2
- Rated Voltage: 415 V
- Frequency: 50-60 Hz
- Voltage Type: AC/DC
- Service Voltage: 12 V
- Rated Impulse Withstand Voltage: 8 kV
- Concurrently Switching Neutral Conductor: Yes
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 1-50 mm²
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature During Operating: -5-40 °C
- Dimensions (H x L x W): 86mm x 80mm x 36mm
- Weight: 0.24 kg
Key Features
- 2-pole design for efficient circuit management.
- Rated current of 80A suitable for various applications.
- IP40 protection rating for reliable performance.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Efficient energy management reduces overall power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Main Switch 2Pole 80A is available now for immediate purchase. Ideal for residential and commercial applications.
