Product Name/Title: NHP DIN-T Miniature Circuit Breaker DC 6kA 2Pole 1A C Curve
Brand: NHP
SKU: DTCBDC201C
Alternatively Known As: Miniature Circuit Breaker, MCB, DC Circuit Breaker
Technical Specifications
- Rated current: 1 A
- Number of poles: 2
- Trip curve: C
- Rated voltage: 415 V
- Frequency: 50-60 Hz
- Voltage type: AC/DC
- Rated ultimate short circuit breaking capacity (ICU) at 125 V DC: 10 kA
- Service voltage (UB) AC: 12 V
- Service voltage (UB) DC: 12 V
- Nominal operating voltage (UN) DC: 500 V
- Rated short circuit breaking capacity (ICN) at 230 VAC: 6 kA
- Rated short circuit breaking capacity (ICN) at 400 VAC: 6 kA
- Max rated operation voltage (UE): 440 V
- Rated insulation voltage (UI): 440 V
- Rated impulse withstand voltage (Uimp): 6 kV
- Concurrently switching neutral conductor: Yes
- Number of protected poles: 2
- Connectable conductor cross section (solid core): 1-35 mm²
- Connectable conductor cross section (multi-wired): 1-25 mm²
- Pollution degree: 3
- Rated surrounding temperature without derating: 30 °C
- Ambient temperature during operating: -25-70 °C
- Dimensions (H x L x W): 86mm x 76mm x 36mm
- Weight: 0.13 kg
Key Features
- Rated current: 1 A
- 2 poles with C curve trip characteristic
- Rated voltage: 415 V
- IP40 protection degree
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
- Complies with AS/NZS 60898 and AS/NZS 60947.2 for safety and performance standards.
Environmental Benefits
- Designed to enhance electrical safety and reduce fire hazards.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Miniature Circuit Breaker DC 6kA 2Pole 1A C Curve is available now for immediate purchase. Ideal for residential and commercial electrical systems.
