DTM10106D
BRAND: NHP

NHP DIN-T Miniature Circuit Breaker MCB 10kA 1 Pole 6A D Curve


$55.00 List price: $73.00
+

Product Name/Title: NHP DIN-T Miniature Circuit Breaker MCB 10kA 1 Pole 6A D Curve

Brand: NHP

SKU: DTM10106D

Alternatively Known As: Miniature Circuit Breaker, MCB, 10kA Circuit Breaker, 1 Pole Circuit Breaker

Technical Specifications
  • Rated Current: 6 A
  • Number of Poles: 1
  • Trip Curve: D
  • Rated Voltage: 240 V
  • Frequency: 50-60 Hz
  • Voltage Type: DC
  • Rated Short Circuit Breaking Capacity: 10 kA
  • Degree of Protection: IP40
  • Connectable Conductor Cross Section: 0.75-35 mm²
  • Rated Insulation Voltage: 440 V
  • Rated Impulse Withstand Voltage: 4 kV
  • Pollution Degree: 3
  • Rated Surrounding Temperature: 30 °C
  • Dimensions (H x L x W): 85mm x 75mm x 17.5mm
  • Weight: 0.12 kg
Key Features
  • 10kA short circuit breaking capacity.
  • D curve for high inrush current applications.
  • Compact design for space-saving installation.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices and retail spaces
  • Industrial: Machinery and equipment protection
Standards & Compliance
  • Complies with AS/NZS 60898 for circuit breakers.
Environmental Benefits
  • Reduces electrical hazards, promoting safety in electrical systems.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Miniature Circuit Breaker MCB 10kA 1 Pole 6A D Curve is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.

DTM10106D-AU-MCB-10kA-1P-D-Curve-Datasheet.pdf (DTM10106D-AU-MCB-10kA-1P-D-Curve-Datasheet.pdf, 189 Kb) [Download]
