DTM10440C
BRAND: NHP

NHP DIN-T Miniature Circuit Breaker MCB 10kA 4 Pole 40A C Curve


$226.70 List price: $301.10
+

Product Name/Title: NHP DIN-T Miniature Circuit Breaker MCB 10kA 4 Pole 40A C Curve

Brand: NHP

SKU: DTM10440C

Alternatively Known As: MCB, Miniature Circuit Breaker, Circuit Protection Device

Technical Specifications
  • Rated Current: 40 A
  • Number of Poles: 4
  • Trip Curve: C
  • Rated Voltage: 415 V
  • Frequency: 50-60 Hz
  • Rated Short Circuit Breaking Capacity: 10 kA at 230 VAC, 10 kA at 400 VAC
  • Degree of Protection: IP40
  • Rated Insulation Voltage: 440 V
  • Rated Impulse Withstand Voltage: 4 kV
  • Connectable Conductor Cross Section: 0.75-35 mm²
  • Dimensions (H x L x W): 85mm x 75mm x 70mm
  • Weight: 0.46 kg
Key Features
  • 4 Pole configuration for comprehensive circuit protection.
  • C Curve trip characteristic suitable for general applications.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
  • Complies with AS/NZS 60898 and AS/NZS 60947.2 for safety and performance standards.
Environmental Benefits
  • Enhances electrical safety, reducing the risk of fire hazards.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Miniature Circuit Breaker MCB 10kA 4 Pole 40A C Curve is available now for immediate purchase. Ideal for residential and commercial electrical installations.

DTM10440C-AU-MCB-10kA-4P-C-Curve-Datasheet.pdf (DTM10440C-AU-MCB-10kA-4P-C-Curve-Datasheet.pdf, 240 Kb) [Download]
