DTM6206C
BRAND: NHP

NHP DIN-T Miniature Circuit Breaker MCB 6kA 2 Pole 6A C Curve


$79.00 List price: $104.90
+

Product Name/Title: NHP DIN-T Miniature Circuit Breaker MCB 6kA 2 Pole 6A C Curve

Brand: NHP

SKU: DTM6206C

Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Breaker 6A, DIN Rail Circuit Breaker

Technical Specifications
  • Rated Current: 6 A
  • Number of Poles: 2
  • Trip Curve: C
  • Rated Voltage: 415 V
  • Frequency: 50-60 Hz
  • Rated Short Circuit Breaking Capacity: 6 kA at 230 VAC, 6 kA at 400 VAC
  • Degree of Protection: IP40
  • Connectable Conductor Cross Section: 0.75-35 mm²
  • Rated Insulation Voltage: 440 V
  • Rated Impulse Withstand Voltage: 4 kV
  • Pollution Degree: 3
  • Rated Surrounding Temperature: 30 °C
  • Dimensions (H x L x W): 85mm x 75mm x 35mm
  • Weight: 0.23 kg
Key Features
  • 6kA short circuit breaking capacity
  • C curve trip characteristic for inductive loads
  • IP40 protection rating
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices, retail spaces, and light industrial applications
Standards & Compliance
  • Complies with AS/NZS 60898 and AS/NZS 60947 for safety and performance standards.
Environmental Benefits
  • Reduces the risk of electrical fires and equipment damage, promoting safety and sustainability.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Miniature Circuit Breaker MCB 6kA 2 Pole 6A C Curve is available now for immediate purchase. Ideal for residential and commercial electrical systems.

DTM6206C-AU-MCB-6kA-2P-C-Curve-Datasheet.pdf (DTM6206C-AU-MCB-6kA-2P-C-Curve-Datasheet.pdf, 207 Kb) [Download]
