SKU: DTRD0610A

BRAND: NHP

NHP DIN-T Residual Current Breaker RCBO 10kA 1 Pole and Switched Neutral 6A C Curve 10mA Type A

$191.20 List price: $253.90

+ −

30 Days Return Delivery Options

Description
Attachments

Product Name/Title: NHP DIN-T Residual Current Breaker RCBO 10kA 1 Pole and Switched Neutral 6A C Curve 10mA Type A

Brand: NHP

SKU: DTRD0610A

Alternatively Known As: Residual Current Breaker, RCBO, Earth Leakage Circuit Breaker

Technical Specifications

Rated Current: 6 A
Rated Voltage: 240 V
Rated Leakage Current: 10 mA
Frequency: 50/60 Hz
Rated Short Circuit Breaking Capacity: 10 kA
Voltage Type: AC
Trip Curve: C
Rated Impulse Withstand Voltage: 4 kV
Tripping Time: 40 ms
Min Service Voltage: 110 V
Max Operating Voltage: 264 V
Rated Residual Make Break Capacity: 6000 A
Number of Poles Total: 2
Degree of Protection: IP40
Electrical Life: 10,000 cycles
Mechanical Life: 20,000 cycles
Operating Temperature: -25 to 70 °C
Dimensions (H x L x W): 85mm x 75mm x 35mm
Weight: 0.2 kg

Key Features

10kA short circuit breaking capacity
Type A leakage current protection
C curve tripping characteristic for general applications
DIN rail mounting for easy installation

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Residential: Homes, apartments, and small commercial buildings
Commercial: Retail and office spaces requiring electrical safety

Standards & Compliance

Complies with AS/NZS 61009 for safety and performance standards.

Environmental Benefits

Enhances electrical safety, reducing the risk of electrical fires and accidents.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP DIN-T Residual Current Breaker RCBO 10kA is available now for immediate purchase. Ideal for residential and commercial electrical safety applications.

DTRD0610A-AU-RCBO-10kA-2P-SN-C-Curve-Datasheet.pdf (DTRD0610A-AU-RCBO-10kA-2P-SN-C-Curve-Datasheet.pdf, 242 Kb) [Download]
