Home/Electrical/Switchgear/MCB/RCD RCBO Combos/NHP DIN-T Residual Current Breaker RCBO 10kA 3 Pole and Switched Neutral 40A C Curve 300mA Type A

Trade Discount 25%

SKU: DTRTN40300A

BRAND: NHP

NHP DIN-T Residual Current Breaker RCBO 10kA 3 Pole and Switched Neutral 40A C Curve 300mA Type A

$805.20 List price: $1,069.20

+ −

30 Days Return Delivery Options

Description
Attachments

Product Name/Title: NHP DIN-T Residual Current Breaker RCBO 10kA 3 Pole and Switched Neutral 40A C Curve 300mA Type A

Brand: NHP

SKU: DTRTN40300A

Alternatively Known As: Residual Current Breaker, RCBO, Earth Leakage Circuit Breaker

Technical Specifications

Rated Current: 40 A
Rated Voltage: 415 V
Frequency: 50/60 Hz
Trip Curve: C
Rated Impulse Withstand Voltage: 4 kV
Tripping Time: 300 ms
Degree of Protection: IP40
Number of Poles: 4 (3 protected)
Electrical Life: 10,000 cycles
Mechanical Life: 20,000 cycles
Operating Temperature: -5 to 55 °C
Dimensions (H x L x W): 117.5mm x 77.1mm x 72mm
Weight: 0.64 kg

Key Features

10 kA short circuit breaking capacity
300 mA rated leakage current for enhanced safety
C curve trip characteristic suitable for general applications
DIN rail mounting for easy installation

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Residential: Homes, apartments, and small commercial buildings
Commercial: Retail and office spaces requiring electrical safety

Standards & Compliance

Complies with AS/NZS 61009 for safety and performance standards.

Environmental Benefits

Enhances electrical safety, reducing the risk of electrical fires and accidents.

Warranty Information

2 years warranty against manufacturing defects.

Available Now

The NHP DIN-T Residual Current Breaker RCBO is available now for immediate purchase, ideal for enhancing electrical safety in various applications.

DTRTN40300A-AU-RCBO-10kA-4P-SN-C-Curve-Datasheet.pdf (DTRTN40300A-AU-RCBO-10kA-4P-SN-C-Curve-Datasheet.pdf, 207 Kb) [Download]
