Product Name/Title: Primo Single door 1270x670 Enclosure, IP66
Brand: B&R Enclosures
SKU: TGBPRM12H06W
Alternatively Known As: Infinity 3G Metering Solution, Primo Power Distribution Unit
Technical Specifications
- Modular Height: 12
- Modular Width: 6
- Materials: Zinc coated steel, aluminium, 316 stainless steel
- Surface Finish: RAL7035
- Height: 1270mm
- Width: 670mm
- Depth: 480mm
- Dimensions (H x L x W): 1270mm x 480mm x 670mm
- Weight: 25 kg
Key Features
- IP66 protection rating
- Includes AS/NZS 61439 compliance documentation
- Robust construction for long service life
- Available in 6 or 10 module wide sizes
- Low profile door lock with provision for authority key barrel or optional padlockable swing handle
- Open sides for easy baying
- Long life, 316 stainless steel hinges
- Large 3mm aluminium gland plate
- Rear rail for cable management according to AS/NZS 3000
- Door stay and A4 document holder supplied as standard
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety and compliance.
Applications
- Power distribution and metering applications up to 630Amps
- Suitable for industrial and commercial environments requiring robust metering solutions
Standards & Compliance
- Complies with AS/NZS 61439 for power distribution and metering.
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Infinity 3G – Primo Range is available now for immediate purchase, ideal for industrial and commercial applications.
