Product Name/Title: Primo Single door 18Hx6W Stainless Encl. IP66
Brand: B&R Enclosures
SKU: TGBPRM18H06W/S
Alternatively Known As: Infinity 3G Metering Solution, Primo Power Distribution Unit
- Modular Height: 18
- Modular Width: 6
- Materials: 316 stainless steel, zinc coated steel, aluminium
- Surface Finish: N4 surface finish
- Height: 1870mm
- Width: 670mm
- Depth: 480mm
- Dimensions (H x L x W): 1870mm x 480mm x 670mm
- Weight: 50 kg
- IP66 protection rating
- Includes AS/NZS 61439 compliance documentation
- Robust construction for long service life
- Available in 6 or 10 module wide sizes
- Low profile door lock with authority key barrel or optional padlockable swing handle
- Open sides for easy baying with side covers available
- Long life, 316 stainless steel hinges
- Large 3mm aluminium gland plate
- Rear rail for cable management according to AS/NZS 3000
- Door stay and A4 document holder supplied as standard
- Professional installation by a qualified electrician is recommended for optimal safety and compliance.
- Power distribution and metering applications up to 630Amps
- Suitable for industrial and commercial environments requiring robust metering solutions
- Complies with AS/NZS 61439 for power distribution equipment.
- Durable materials reduce the need for frequent replacements, minimizing waste.
1 year warranty against manufacturing defects.
The Infinity 3G – Primo Range is available now for immediate purchase, ideal for industrial and commercial applications.
