Product Name/Title: S+S CA8 Auxiliary Contact with 4NO Contacts
Brand: NHP
SKU: CA8P40
Alternatively Known As: Auxiliary Contact Block, Mini Auxiliary Contact
Technical Specifications
- Rated Insulation Voltage (Ui): 690 V
- Rated Operation Current (Ie) at 40°C: 10 A
- Rated Operation Current (Ie) at AC 15 24 V: 3 A
- Rated Operation Current (Ie) at AC 15 120 V: 3 A
- Rated Operation Current (Ie) at AC 15 240 V: 2 A
- Rated Operation Current (Ie) at AC 15 400 V: 1.2 A
- Rated Operation Current (Ie) at DC 13 24 V: 2.3 A
- Rated Operation Current (Ie) at DC 13 110 V: 0.55 A
- Rated Operation Current (Ie) at DC 13 220 V: 0.27 A
- Minimum Contact Rating Current: 2 mA
- Minimum Contact Rating Voltage: 15 V
- Rated Operation Current (Ie) at AC 15 230 V: 2 A
- Dimensions (H x L x W): 100mm x 75mm x 50mm
- Weight: 0.5 kg
Key Features
- 4 Normally Open (NO) contacts for versatile applications.
- Top mounting method for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: Electrical installations requiring auxiliary contacts
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Designed for energy efficiency in electrical systems.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CA8 Auxiliary Contact with 4NO Contacts is available now for immediate purchase. Ideal for industrial and commercial electrical installations.
