Product Name/Title: S+S CS8 Auxiliary Contact with 4NO Contacts
Brand: NHP
SKU: CS8P40E
Alternatively Known As: Auxiliary Contact Block, Control Relay Contact
Technical Specifications
- Number of Contacts: 4 NO
- Rated Insulation Voltage: 690 V
- Rated Operation Current (40°C): 10 A
- Rated Operation Current (AC 15, 24 V): 3 A
- Rated Operation Current (AC 15, 120 V): 3 A
- Rated Operation Current (AC 15, 240 V): 2 A
- Rated Operation Current (AC 15, 400 V): 1.2 A
- Rated Operation Current (DC 13, 24 V): 2.3 A
- Rated Operation Current (DC 13, 110 V): 0.55 A
- Rated Operation Current (DC 13, 220 V): 0.27 A
- Minimum Contact Rating Current: 2 mA
- Minimum Contact Rating Voltage: 15 V
- Rated Operation Current (AC 15, 230 V): 2 A
- Mounting Method: Top mounting
- Dimensions (H x L x W): 50mm x 100mm x 100mm
- Weight: 0.5 kg
Key Features
- 4 Normally Open (NO) contacts for versatile control applications.
- Rated insulation voltage of 690 V for high voltage applications.
- Top mounting method for easy installation.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Control systems, automation equipment
- Commercial: Electrical panels, machinery control
Standards & Compliance
- Complies with AS/NZS 60950 for safety and performance standards.
Environmental Benefits
- Durable design reduces the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS8 Auxiliary Contact with 4NO Contacts is available now for immediate purchase. Ideal for industrial and commercial control applications.
