Product Name/Title: S+S CS8 Relay 12VDC Coil 4NO Contact
Brand: NHP
SKU: CS8C40E12VDC
Alternatively Known As: Control Relay, Mini Relay, 12V Relay
Technical Specifications
- Number of Auxiliary Contacts (NO): 4
- Rated Operation Current (Ie 400 V): 10 A
- Max Rated Operation Voltage (UE AC): 690 V
- Voltage Type for Actuating: DC
- Control Supply Voltage (Us at DC): 12 V
- Power Consumption DC Coil Pickup: 3 W
- Power Consumption DC Coil Hold In: 3 W
- Mounting Method: DIN-rail/screw
- Connection Type Auxiliary Circuit: Screw connection
- Dimensions (H x L x W): 56mm x 53mm x 45mm
- Weight: 0.2 kg
Key Features
- Mini control relay with 4 normally open contacts.
- Rated for 10 A operation at 400 V.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Automation systems, control panels
- Commercial: HVAC systems, lighting control
- General: Any application requiring relay control
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Efficient power consumption reduces energy waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The S+S CS8 Relay 12VDC Coil 4NO Contact is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable control.
