Product Name/Title: S+S KT9 Motor Protection Circuit Breaker KTA9 40H Frame D 4.0 to 6.3A
Brand: NHP
SKU: KTA940H6P3A
Alternatively Known As: Motor Protection Circuit Breaker, KT9 Circuit Breaker, NHP Motor Breaker
- Rated Permanent Current: 6.3 A
- Max Rated Operation Voltage: 690 V
- Rated Short Circuit Breaking Capacity: 100 kA
- Rated Operation Power at AC 3 400 V: 2.2 kW
- Type of Control Element: Turn handle
- Type of Electrical Connection: Screw connection
- Number of Poles: 3
- Degree of Protection: IP2X
- Max Tightening Torque: 2.5 Nm
- Dimensions (H x L x W): 96.3mm x 93.7mm x 45mm
- Weight: 0.39 kg
- Thermomagnetic switch-off technique for reliable protection.
- Adjustable long-time overload protection from 4 to 6.3 A.
- High breaking capacity of 100 kA at 400 V AC.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Industrial: Motor protection in various machinery
- Commercial: Equipment requiring overload protection
- Complies with AS/NZS 3000 for electrical installation safety.
- Enhances equipment longevity by preventing overload damage.
1 year warranty against manufacturing defects.
The S+S KT9 Motor Protection Circuit Breaker KTA9 40H Frame D 4.0 to 6.3A is available now for immediate purchase, ideal for industrial and commercial applications.
