FLSCSCOM440
BRAND: CERTECH

SC-SC OM4 Duplex Fibre Lead, Aqua LSZH Jacket - 40m


$104.70 List price: $136.10
+

Product Name/Title: SC-SC OM4 Duplex Fibre Lead, Aqua LSZH Jacket - 40m

Brand: Certech

SKU: FLSCSCOM440

Alternatively Known As: OM4 Duplex Fibre Lead, Aqua Fibre Patch Lead, SC-SC Fibre Cable

Technical Specifications
  • Core Diameter: 50/125um
  • Clad Diameter: 50/125um
  • Effective Modal Bandwidth: Minimum 4700 MHz-km
  • Transmission: Supports 10 Gb/s serial transmission
  • Material: Aramid Yarn and LSZH Jacket
  • Dimensions (H x L x W): 10mm x 40000mm x 10mm
  • Weight: 0.5 kg
Key Features
  • 850nm laser-optimised graded-index multimode optical fibre
  • Supports up to 550-metre link lengths
  • Compatible with 10 Gb/s Ethernet applications
  • DMD controlled index profile for reliable transmission
  • Manufactured using advanced Plasma activated Chemical Vapor Deposition (PCVD) process
Professional Installation Requirements
  • Professional installation is recommended for optimal performance and safety.
Applications
  • Data centers and server rooms
  • Telecommunications networks
  • High-speed data transmission in commercial buildings
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
  • LSZH jacket reduces toxic emissions in case of fire.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The SC-SC OM4 Duplex Fibre Lead, Aqua LSZH Jacket - 40m is available now for immediate purchase. Ideal for high-speed data transmission applications.

Specification Sheet (flscscom440_u.pdf, 287 Kb) [Download]
