SENS010

SENSOR ADJ I/Motion 3 Wire 1000W RECT Blk IP65 w/override


$68.60 List price: $89.50
+

Product Name/Title: SENSOR ADJ I/Motion 3 Wire 1000W RECT Blk IP65 w/override

Brand: CLA Lighting

SKU: SENS010

Alternatively Known As: PIR Motion Sensor, Infrared Motion Detector, Adjustable Motion Sensor

Technical Specifications
  • Input voltage: 220-240V 50/60Hz
  • Rated Load: 2000W HAL/ 1000W CFL/ 1000W LED
  • Time Delay: Min.10sec±3sec; Max.30min±2min
  • Ambient Light: 3-2000Lux
  • Ambient temperature: -20 to 40°C
  • Working Humidity: <93%RH
  • Power Consumption: approx. 0.5W
  • Installation Height: 2.2-6m
  • Housing Material: PC
  • IP rating: IP65
  • UV resistant
  • 3 wire
  • Day/Night recognition
  • Dimensions (H x L x W): 100mm x 100mm x 100mm
  • Weight: 0.5 kg
Key Features
  • Adjustable infrared PIR surface mounted sensors
  • Detection Range: 360°
  • Detection Distance: 20m Max (<24°C)
  • Manual override feature
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, garages, outdoor areas
  • Commercial: Offices, retail spaces, warehouses
  • General: Any location requiring motion detection for lighting control
Standards & Compliance
  • Complies with AS/NZS 3820 for essential safety requirements for electrical equipment.
Environmental Benefits
  • Energy-efficient operation reduces power consumption.
  • Enhances safety and security in outdoor areas.
Warranty Information

5 year replacement warranty.

Available Now

The CLA Lighting Adjustable Infrared PIR Motion Sensor is available now for immediate purchase. Ideal for residential and commercial spaces, providing efficient motion detection.
