Product Name/Title: Terasaki TemBreak PRO MCCB 160 Frame 36kA 2P 75A Fix. Therm. Fix. Mag.
Brand: NHP
SKU: P160F2275FF
Alternatively Known As: MCCB, Circuit Breaker, Thermal Magnetic Circuit Breaker
Technical Specifications
- Rated Current: 75 A
- Number of Poles: 2
- Max Rated Operation Voltage: 690 V
- Rated Ultimate Short Circuit Breaking Capacity: 36 kA
- Rated Service Short Circuit Breaking Capacity: 36 kA
- Rated Insulation Voltage: 800 V
- Rated Impulse Withstand Voltage: 8 kV
- Electrical Life: 30,000 cycles
- Mechanical Life: 50,000 cycles
- Cable Cross Section Range: 1.5-70 mm²
- Pollution Degree: 3
- Rated Surrounding Temperature: -5 to 70 °C
- Dimensions (H x L x W): 130mm x 95.5mm x 60mm
- Weight: 0.7 kg
Key Features
- Fixed thermal and magnetic trip unit for reliable protection.
- Rated short circuit breaking capacity of 36 kA at 415 V.
- Compact design with a frame size rating of 160 A.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Power distribution and protection in commercial and industrial settings
- General: Suitable for various electrical installations requiring circuit protection
Standards & Compliance
- Complies with AS/NZS IEC 60947.2 for circuit breakers.
Environmental Benefits
- Designed for energy efficiency, reducing power loss during operation.
Warranty Information
Standard warranty applies, please check with the supplier for details.
Available Now
The Terasaki TemBreak PRO MCCB 160 Frame 36kA 2P 75A is available now for immediate purchase. Ideal for industrial and commercial applications requiring reliable circuit protection.
