Home/Electrical/Switchgear/Circuit Breakers/Circuit Breakers A/C/Terasaki TemBreak PRO MCCB 250 Frame 70kA 4P 250A Basic Electronic

Trade Discount 25%

SKU: P250H4250BE

BRAND: NHP

Terasaki TemBreak PRO MCCB 250 Frame 70kA 4P 250A Basic Electronic

$2,030.20 List price: $2,695.80

+ −

30 Days Return Delivery Options

Description
Attachments

Product Name/Title: Terasaki TemBreak PRO MCCB 250 Frame 70kA 4P 250A Basic Electronic

Brand: NHP

SKU: P250H4250BE

Alternatively Known As: MCCB, Molded Case Circuit Breaker, Circuit Breaker 250A

Technical Specifications

Rated Current: 250 A
Number of Poles: 4
Max Rated Operation Voltage: 690 V
Rated Ultimate Short Circuit Breaking Capacity: 70 kA
Rated Service Short Circuit Breaking Capacity: 50 kA
Type of Protection Trip Unit: Electronic release
Trip Curve: LSI
Long Time Overload Protection Adjustment Range: 92-250 A
Instantaneous Protection Adjustment Range: 750-2750 A
Rated Frequency: 50-60 Hz
Rated Insulation Voltage: 800 V
Rated Short Circuit Breaking Capacity (ICU): 6 kA
Rated Impulse Withstand Voltage: 8 kV
Power Loss: 45 W
Mechanical Life: 30000 cycles
Max Vibration Acceleration: 19 m/s²
Cable Cross Section Range: 35-185 mm²
Pollution Degree: 3
Rated Surrounding Temperature: 50 °C
Maximum Operating Temperature: 70 °C
Dimensions (H x L x W): 165mm x 95.5mm x 140mm
Weight: 2 kg

Key Features

Electronic release for precise protection.
High breaking capacity of 70 kA.
Suitable for isolation and reverse connection.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Power distribution in manufacturing facilities
Commercial: Electrical installations in commercial buildings
General: Protection of electrical circuits in various applications

Standards & Compliance

Complies with AS/NZS IEC 60947.2 for safety and performance standards.

Environmental Benefits

Designed for long electrical life, reducing waste and resource consumption.

Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Terasaki TemBreak PRO MCCB 250 Frame 70kA 4P 250A Basic Electronic is available now for immediate purchase. Ideal for industrial and commercial electrical installations.

P250H4250BE-AU-TBP-MCCB-250AF-Datasheet.pdf (P250H4250BE-AU-TBP-MCCB-250AF-Datasheet.pdf, 1,294 Kb) [Download]
