1/2 Rupture Disc | 400psi Pressure Rating | High Discharge Capacity | CE Certified | by Aspen Pumps
The 1/2 Rupture Disc with a 400psi pressure rating is designed for reliable pressure relief in refrigeration systems. Ideal for use on liquid receivers above the liquid line, this high-quality metal alloy disc is compatible with all fluorinated refrigerants and is individually tested for accuracy. Ensure safety and compliance in HVAC applications with this certified rupture disc.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 1/2 Rupture Disc | 400psi Pressure Rating | High Discharge Capacity | CE Certified | by Aspen Pumps
Brand: Aspen Pumps
SKU: A17971-400
Alternatively Known As: Pressure Relief Rupture Disc, 1/2 inch Rupture Disc, Refrigeration Rupture Disc
Technical Specifications
- Pressure Rating: 400psi / 2760kpa
- Size: 1/2 inch
- Material: High-quality metal alloy
- Certification: CE, NB, ASME Code 15, RoHS
- Tested and hand calibrated for accuracy
- High discharge capacity suitable for liquid receivers
- Dimensions (H x L x W): 10mm x 50mm x 50mm
- Weight: 0.2 kg
Key Features
- AS Compliant, Certified by CE, NB, ASME Code 15, RoHS
- Designed for use on liquid receivers above the liquid line
- Compatible with all fluorinated refrigerants
- High discharge capacity
- Individually tested and hand calibrated
Professional Installation Requirements
- Installation should be performed by a qualified technician familiar with pressure relief devices and refrigeration systems to ensure safety and compliance.
Applications
- Use on liquid receivers above the liquid line
- Compatible with refrigeration systems using fluorinated refrigerants
- Pressure relief in HVAC and refrigeration systems
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Prevents system overpressure, reducing risk of leaks and refrigerant release
- Compatible with environmentally safer fluorinated refrigerants
Warranty Information
Warranty details available upon request; typically includes coverage against manufacturing defects.
Available Now
The Aspen Pumps 1/2 Rupture Disc 400psi/2760kpa is available for immediate purchase, ideal for refrigeration and HVAC system safety applications.
