1/4 MSAE Single Pressure Control Manual Reset | 0-6 Bar Pressure Range | 1 Bar Differential | by Aspen Pumps
The 1/4 MSAE Single Pressure Control Manual Reset is designed for effective mechanical pressure control in HVAC and refrigeration systems. With a pressure range of 0-6 bar and a 1 bar differential, it ensures optimal system efficiency and pump protection. Ideal for industrial and commercial applications, this reliable pressure switch helps prevent overpressure and reduces energy waste.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 1/4 MSAE Single Pressure Control Manual Reset | 0-6 Bar Pressure Range | 1 Bar Differential | by Aspen Pumps
Brand: Aspen Pumps
SKU: 721-SP06-M
Alternatively Known As: Manual Reset Pressure Switch, Single Pressure Control Switch, 1/4 MSAE Pressure Control
Technical Specifications
- Pressure Range: 0 - 6 bar
- Differential Bar: Manual reset 1 bar
- Safe Working Pressure (SWP): 16.5 bar
- Connection Type: 1/4 MSAE
- Type: Mechanical pressure control with manual reset
- Dimensions (H x L x W): 70mm x 40mm x 50mm
- Weight: 0.3 kg
Key Features
- Manual reset pressure control
- Pressure range: 0 - 6 bar
- Differential pressure: 1 bar
- Maximum working pressure (SWP): 16.5 bar
- 1/4 MSAE connection
Professional Installation Requirements
- Installation should be performed by a qualified technician to ensure proper setup and safety compliance.
Applications
- Mechanical pressure control in HVAC systems
- Pump protection and control
- Industrial and commercial refrigeration systems
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Helps optimize system efficiency by maintaining correct pressure levels
- Reduces energy waste by preventing system overpressure
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Aspen 1/4 MSAE Single Pressure Control Manual Reset LP is available now for immediate purchase. Ideal for HVAC and refrigeration system pressure management.
