1-Way Push-Button Switch | Round Design | IP40 Rated | Glossy White | @Each of 1 | by Legrand
The 1-way push-button switch is designed for seamless home and office lighting control. Featuring a round design and IP40 rating, this switch is perfect for flush-mounted installations. Made from halogen-free thermoplastic, it ensures durability and environmental safety, making it an ideal choice for both residential and commercial applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 1-Way Push-Button Switch | Round Design | IP40 Rated | Glossy White | @Each of 1 | by Legrand
Brand: Legrand
SKU: 573001
Alternatively Known As: Legrand Arteor push button switch, 1 module push button, round push button switch, white electrical switch
Technical Specifications
- Nominal voltage: 250 V AC
- Rated current: 6 A
- Number of modules: 1 middle module
- Number of poles: 1
- Number of contacts normally open: 1
- Number of contacts normally closed: 0
- Mounting method: Flush-mounted
- Connection type: Screwed terminal
- Material: Thermoplastic, halogen free
- Surface finish: Glossy
- Degree of protection: IP40
- Impact resistance: IK04
- Operating temperature: -5 to 50 °C
- Storage temperature: -10 to 70 °C
- Frequency: 50-60 Hz
- Cable section: 4-4 mm²
- Dimensions (H x L x W): 45mm x 42.2mm x 22.5mm
- Weight: 0.1 kg
Key Features
- 1-way push-button switch with rocker operation
- Rated current 6A at 250V AC
- Flush-mounted with snap fastening
- Single middle module size (22.5 mm width)
- White glossy thermoplastic material
- IP40 rated for protection against solid objects
- IK04 impact resistance
- Screwed terminal connection
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper mounting.
Applications
- Residential: Home lighting control
- Commercial: Office and retail lighting control
- General: Suitable for flush-mounted electrical switch installations
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Halogen-free thermoplastic material reduces environmental impact
- Durable design extends product life and reduces waste
Warranty Information
Legrand standard warranty applies, typically 2 years against manufacturing defects.
Available Now
The Legrand Arteor 1-way round push-button switch is available for immediate purchase, ideal for residential and commercial lighting control applications.
