10/100Base-TX to 100Base-FX Multimode ST Fibre Media Converter | Auto-Negotiation RJ45 | 1024 MAC Address Capacity | by SERVEREDGE
The 10/100Base-TX to 100Base-FX Multimode ST Fibre Media Converter is designed for seamless network extension over fiber optic cables. With features like auto-negotiation RJ45 and a capacity for 1024 MAC addresses, it's perfect for connecting copper networks to fiber in office and industrial environments. Built for reliability, it ensures efficient data transmission while reducing electromagnetic interference.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 10/100Base-TX to 100Base-FX Multimode ST Fibre Media Converter | Auto-Negotiation RJ45 | 1024 MAC Address Capacity | by SERVEREDGE
Brand: SERVEREDGE
SKU: SED-100MST
Alternatively Known As: Fiber Media Converter, Ethernet to Fiber Converter, 10/100Base-TX to 100Base-FX Converter, Multimode Fiber Converter
Technical Specifications
- Latency: < 4.2 μs (LIFO)
- Throughput @ 100Base: 148,809 pps (64-byte packets)
- Speed: 100BaseTX: 100/200 Mbps half/full duplex, 10BaseT: 10/20 Mbps half/full duplex
- Switching Method: Store-and-Forward
- Maximum MAC Addresses: 1,024 entries
- Memory: 256 KB
- Fiber Interface (Multimode): LED type
- Wavelength: 1300 nm nominal (1270 nm max, 1380 nm min)
- Maximum Output Power: -14.0 dBm
- Minimum Output Power: -20.0 dBm
- Sensitivity: -33.0 dBm
- Maximum Input Power: -8.0 dBm
- Link Power Budget: 13.0 dB
- LED Indicators: Power status, RJ-45 port speed, LNK/ACT, FDX/COL
- Dimensions (H x L x W): 25mm x 120mm x 100mm
- Weight: 0.3 kg
Key Features
- Built-in twisted-pair port 10/100 switch
- Auto-negotiation RJ45 connector with Auto-MDIX
- Supports SC, ST, MTRJ or LC fiber connectors
- LED indicators for power, link, and activity
- Link fault signaling compatible with managed switches
- 1024 MAC address capacity
- Store and forward architecture
- Full and half duplex operation
- Singlemode fiber spans up to 10 km
- Wall or chassis mountable
- Compliant with IEEE 802.3 10BaseT, IEEE 802.3u 100BaseTX, and IEEE 802.3u 100BaseFX standards
Professional Installation Requirements
- Installation by a qualified network technician or electrician is recommended to ensure proper fiber optic cable handling and device configuration.
Applications
- Network infrastructure for extending Ethernet connections over fiber optic cables
- Connecting 10/100Base-TX copper networks to 100Base-FX multimode fiber networks
- Suitable for office, data center, and industrial network environments
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Enables network extension over fiber optic cables reducing electromagnetic interference and improving energy efficiency in data transmission
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Serveredge 10/100Base-TX to 100Base-FX Multimode ST Fibre Media Converter is available now for immediate purchase. Ideal for extending Ethernet networks over fiber in commercial and industrial applications.
