10/100Base-TX to 100Base-FX Singlemode SC Fibre Media Converter | Low Latency < 4.2 μs | 100/200 Mbps Support | by SERVEREDGE
The 10/100Base-TX to 100Base-FX Singlemode SC Fibre Media Converter is designed for seamless network infrastructure upgrades, converting Ethernet to fibre with low latency of less than 4.2 μs. Ideal for enterprise networks and data centers, it supports 100BaseTX at 100/200 Mbps and features a robust store-and-forward switching method, ensuring efficient data handling and long-distance transmission.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 10/100Base-TX to 100Base-FX Singlemode SC Fibre Media Converter | Low Latency < 4.2 μs | 100/200 Mbps Support | by SERVEREDGE
Brand: SERVEREDGE
SKU: SED-100SSC-40
Alternatively Known As: Fibre Media Converter, Ethernet to Fibre Converter, 10/100Base-TX to 100Base-FX Converter, Singlemode Fibre Media Converter
Technical Specifications
- Latency: < 4.2 μs (LIFO)
- Throughput @ 100Base: 148,809 pps (64-byte packets)
- Speed: 100BaseTX: 100/200 Mbps half/full duplex
- Speed: 10BaseT: 10/20 Mbps half/full duplex
- Switching Method: Store-and-Forward
- Maximum MAC Addresses: 1,024 entries
- Memory: 256 KB
- Fibre Interface Type: MQW Laser
- Wavelength: 1300 nm nominal (1261 nm max, 1360 nm min)
- Maximum Output Power: -5.0 dBm
- Minimum Output Power: -12.0 dBm
- Sensitivity: -35.0 dBm
- Maximum Input Power: -5.0 dBm
- Link Power Budget: 23.0 dB
- Operating Temperature: 0°C to 40°C
- Storage Temperature: -25°C to 70°C
- Relative Humidity: 10% to 90%, non-condensing
- Power: External 12V DC, 600 mA adapter
- Power Consumption: 5 Watts maximum
- Dimensions (H x L x W): 23mm x 81mm x 110mm
- Weight: 0.15 kg
Key Features
- Low latency of less than 4.2 μs (LIFO)
- Supports 100BaseTX at 100/200 Mbps for half/full duplex
- Supports 10BaseT at 10/20 Mbps for half/full duplex
- Store-and-Forward switching method
- Maximum MAC address entries: 1,024
- 256 KB memory for efficient data handling
- Singlemode fibre interface with MQW Laser
- Wavelength nominal 1300 nm
- Link power budget of 23.0 dB
Professional Installation Requirements
- Installation by a qualified network technician or electrician is recommended to ensure proper setup and compliance with safety standards.
Applications
- Network infrastructure for converting 10/100Base-TX Ethernet to 100Base-FX fibre
- Suitable for long-distance data transmission over singlemode fibre optic cables
- Ideal for enterprise networks, data centers, and telecommunications
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Enables use of fibre optic cabling which reduces electromagnetic interference and signal loss
- Supports energy-efficient network infrastructure by enabling longer distance connections without repeaters
Warranty Information
Standard manufacturer warranty applies. Please refer to SERVEREDGE warranty policy for details.
Available Now
The Serveredge 10/100Base-TX to 100Base-FX Singlemode SC Fibre Media Converter is available for immediate purchase, ideal for network infrastructure upgrades requiring reliable fibre optic connectivity.
