10/100Base-TX to 100Base-FX Singlemode SC Fibre Media Converter | Low Latency & High Throughput | by SERVEREDGE
The 10/100Base-TX to 100Base-FX Singlemode SC Fibre Media Converter is designed for seamless network infrastructure upgrades, converting Ethernet to fibre with low latency under 4.2 microseconds. Ideal for enterprise and data center connectivity, it supports 100/200 Mbps speeds and features a robust store-and-forward switching method, ensuring efficient data handling and reliable long-distance communication.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 10/100Base-TX to 100Base-FX Singlemode SC Fibre Media Converter | Low Latency & High Throughput | by SERVEREDGE
Brand: SERVEREDGE
SKU: SED-100SSC-100
Alternatively Known As: Media Converter, Fibre Media Converter, Ethernet to Fibre Converter, 10/100Base-TX to 100Base-FX Converter
Technical Specifications
- Latency: < 4.2 μs (LIFO)
- Throughput @ 100Base: 148,809 pps (64-byte packets)
- Speed: 100BaseTX: 100/200 Mbps half/full duplex
- Speed: 10BaseT: 10/20 Mbps half/full duplex
- Switching Method: Store-and-Forward
- Maximum MAC Addresses: 1,024 entries
- Memory: 256 KB
- Fibre Interface Type: MQW Laser
- Wavelength: 1300 nm nominal (1270-1350 nm range)
- Maximum Output Power: +3.0 dBm
- Minimum Output Power: -3.0 dBm
- Sensitivity: -37.0 dBm
- Maximum Input Power: -0.0 dBm
- Link Power Budget: 34.0 dB
- Operating Temperature: 0°C to 40°C
- Storage Temperature: -25°C to 70°C
- Relative Humidity: 10% to 90%, non-condensing
- Power: External 12V DC, 600 mA adapter
- Power Consumption: 5 Watts maximum
- Dimensions (H x L x W): 23mm x 81mm x 110mm
- Weight: 0.15 kg
Key Features
- Low latency of less than 4.2 microseconds (LIFO)
- Supports 100BaseTX speeds of 100/200 Mbps for half/full duplex
- Supports 10BaseT speeds of 10/20 Mbps for half/full duplex
- Store-and-Forward switching method
- Maximum MAC address entries: 1,024
- 256 KB memory for efficient data handling
- Singlemode fibre interface with MQW Laser
- Wavelength nominal 1300 nm (range 1270-1350 nm)
- Maximum output power +3.0 dBm, minimum output power -3.0 dBm
- Sensitivity -37.0 dBm and link power budget of 34.0 dB
- Compact physical size: 110mm x 81mm x 23mm
- Lightweight at 150 grams
- Operating temperature range 0°C to 40°C
- Power consumption maximum 5 Watts with external 12V DC adapter
Professional Installation Requirements
- Installation by a qualified network technician or electrician is recommended to ensure proper fibre optic and electrical connections.
Applications
- Network infrastructure for converting 10/100Base-TX Ethernet to 100Base-FX fibre
- Enterprise and data center network connectivity
- Long distance fibre optic communication links
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Enables use of fibre optic cabling which reduces electromagnetic interference and signal loss over long distances
- Supports energy-efficient network infrastructure with low power consumption
Warranty Information
Standard manufacturer warranty applies; please refer to SERVEREDGE for specific warranty terms.
Available Now
The Serveredge 10/100Base-TX to 100Base-FX Singlemode SC Fibre Media Converter is available for immediate purchase, ideal for upgrading and extending network infrastructure with fibre optic connectivity.
