10-Port Gigabit Desktop Switch TP-Link DS110GMP Ness
Ness TP-Link 10-port gigabit desktop switch. Ideal for network installs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: DS110GMP, 10-Port Gigabit Unmanaged Switch, 8-Port PoE+ Switch, TP-Link Omada Desktop Switch
Technical Specifications
- Network Ports: 9 x 10/100/1000 Mbps RJ45 ports and 1 x Gigabit combo SFP/RJ45 port
- PoE Standard: IEEE 802.3af/at PoE+
- PoE Ports: Ports 1–8, up to 30 W per port
- PoE Power Budget: 123 W
- Switching Capacity: 20 Gbps
- MAC Address Table: 4K, automatic learning and ageing
- Forwarding Method: Store-and-forward
- Network Cable Support: Cat 3, Cat 4, Cat 5, Cat 5e and above, depending on speed
- Power Supply: 100–240 V AC, 50/60 Hz; 53.5 V DC, 2.43 A output
- Maximum Power Consumption: 141.40 W with full 123 W PoE load
- Operating Mode: Unmanaged, plug and play
- Housing: Steel case with fanless design
- Mounting: Desktop or wall mountable
- Extend Mode: Up to 250 m for ports 1–4 at reduced speed
- Dimensions (H x L x W): 26mm x 209mm x 126mm
- Weight: 0.6 kg
Key Features
- Ten Gigabit network ports for small commercial and security installations
- Eight PoE+ ports provide data and power over a single Ethernet cable
- One Gigabit combo SFP/RJ45 port supports copper or fibre uplink connectivity
- 123 W total PoE budget with up to 30 W available per PoE port
- Fanless design for quiet operation and reduced mechanical maintenance
- Extend Mode supports transmission distances up to 250 m on compatible ports
- Priority Mode gives ports 1–2 higher traffic priority
- Isolation Mode separates selected client traffic for improved network security
- PoE Auto Recovery automatically restarts unresponsive powered devices
- Unmanaged plug-and-play operation requires no software configuration
Applications
- IP camera and video surveillance installations
- Wireless access point and network gateway installations
- VoIP telephone and intercom systems
- Small business and commercial Ethernet networks
- Building security, access control and monitoring systems
- Network installations requiring PoE power and fibre or copper uplink flexibility
Standards & Compliance
- AS/NZS 62368.1:2022 – applicable safety standard for audio, video and information and communication technology equipment; verify product-specific declaration of conformity
- AS/NZS 4417.1 and AS/NZS 4417.2 – Regulatory Compliance Mark requirements for applicable electrical and electronic equipment
Environmental Benefits
- Fanless operation avoids fan-related component replacement and reduces operating noise
- PoE delivers power and data through one Ethernet cable, reducing separate power cabling and associated installation materials
- Steel housing is durable and recyclable at end of service life
- Automatic power management and low no-load consumption can reduce energy use in lightly loaded installations
- Long warranty period and robust construction may extend service life and reduce replacement waste
Warranty Information
TP-Link Australia provides a 5-year limited warranty for Omada indoor switches purchased in Australia or New Zealand through an authorised retailer, subject to the current TP-Link warranty terms and proof of purchase.
Available Now
Available through Ness and authorised Australian TP-Link distributors, subject to distributor stock and product availability.
