10kVA 10kW Online UPS 10 Battery Banks Rack Tower Enduro
Enduro 10kVA 10kW online double conversion UPS features 10 battery banks, 10 year design life batteries and rack or tower mounting. Ideal for servers.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Enduro EN10-10-RT-LL, Enduro 10kVA UPS, Rack/Tower Online UPS, Server UPS
Technical Specifications
- Model: EN10-10-RT-LL
- Rated Capacity: 10kVA / 10kW
- UPS Topology: Online double conversion
- Battery Configuration: 10 extended battery modules or battery banks
- Battery Design Life: 10 years
- Mounting: Rack or tower
- Load Type: Suitable for sensitive equipment including servers
- Output Configuration: 1:1
- Dimensions Basis: Approximate primary UPS module dimensions; battery-bank dimensions vary by configuration
- Dimensions (H x L x W): 130mm x 700mm x 440mm
- Weight: 75 kg
Key Features
- 10kVA and 10kW power capacity
- Online double-conversion technology for continuous voltage and frequency conditioning
- Designed for sensitive electronic equipment such as servers and network infrastructure
- Supplied with 10 extended battery modules or battery banks
- 10-year design-life batteries
- Convertible rack or tower mounting
- Supports extended runtime for critical loads
- Software monitoring support via the associated UPSilon software platform
Professional Installation Requirements
- Installation should be performed by a suitably qualified electrical contractor. The UPS requires appropriate mains input, output, isolation, earthing, ventilation and battery-system installation in accordance with the manufacturer's instructions and applicable Australian electrical requirements, including AS/NZS 3000 where relevant.
Applications
- Server rooms and data centres
- Network and telecommunications infrastructure
- Storage and critical IT equipment
- Industrial control and automation systems
- Medical, laboratory and other sensitive electronic equipment
- Facilities requiring extended runtime during mains interruptions
Standards & Compliance
- AS 62040.1:2019 – Uninterruptible power systems, general and safety requirements; applicable standard for UPS equipment, with product-specific certification to be confirmed from the supplier
- AS/NZS 3000 – Electrical installations, applicable to the fixed electrical installation and connection of the UPS
Environmental Benefits
- Replaceable extended battery modules can support longer equipment service life and reduce premature UPS replacement
- Lead-acid battery components are recyclable through suitable battery recycling programs
- Double-conversion power conditioning can reduce equipment stress and associated electronic waste caused by poor power quality
- Long-design-life batteries may reduce battery replacement frequency compared with shorter-life alternatives
Warranty Information
No ENDURO-specific warranty period for this configuration was identified in the available manufacturer or distributor information. Confirm warranty coverage for the UPS electronics, battery modules, installation and on-site service with the authorised Australian distributor before purchase.
Available Now
Available through ENDURO and authorised Australian electrical, power-protection and data-infrastructure distributors; distributor confirmation is required for current stock and lead time.
UPS Sizing Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
