10kVA 10kW Online UPS 40x 120Ah Battery Bank Tower Enduro
Enduro 10kVA 10kW online double conversion UPS features 40x 120ah battery bank, 10 year design life batteries and onsite cabinet assembly. Ideal for servers.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: ENDURO Long Run Online UPS, EN10-120-40T-LL, 10kVA Double-Conversion UPS
Technical Specifications
- UPS Capacity: 10kVA / 10kW
- Topology: Online double conversion
- Battery Bank: 40 x 12V 120Ah sealed lead-acid batteries
- Battery Design Life: 10 years
- Output Power Factor: 1.0
- Mounting: Tower UPS with free-standing floor-mounted battery bank
- Display: Interactive LCD screen
- Generator Compatibility: Yes
- Charging: Fast-charging system
- Communications: Optional SNMP and relay interfaces
- Battery Dimensions: 222H x 328W x 172D mm per PSS120 battery
- UPS Model / Item Number: EN10-120-40T-LL
- Applicable UPS Safety Standard: AS 62040.1:2019; installation should also follow AS/NZS 3000:2018. Product-specific certification was not independently verified. ([mssdatasolutions.com.au](https://www.mssdatasolutions.com.au/p/power-supplies-batteries/uninterruptible-power-supplies/line-interactive-ups/en10-120-40t-ll))
- Dimensions (H x L x W): 2000mm x 1200mm x 800mm
- Weight: 1600 kg
Key Features
- Provides regulated, uninterrupted power using online double-conversion technology
- Configured for sensitive loads including servers, computers, telecommunications and industrial equipment
- Includes 40 x 120Ah batteries for extended runtime
- Ten-year design-life battery configuration
- Battery banks are floor-mounted and free-standing
- Onsite battery cabinet assembly is required
- Tower-mounted UPS control unit
- Interactive LCD monitoring
- Generator-compatible operation
- Optional SNMP and relay communications for remote monitoring
Professional Installation Requirements
- Installation, battery cabinet assembly, electrical connection and commissioning should be completed by a licensed electrical contractor or suitably qualified UPS technician. Follow the manufacturer’s installation instructions, AS/NZS 3000:2018 and applicable battery safety requirements. Onsite cabinet assembly is required. ([mssdatasolutions.com.au](https://www.mssdatasolutions.com.au/p/power-supplies-batteries/uninterruptible-power-supplies/line-interactive-ups/en10-120-40t-ll))
Applications
- Server rooms and data centres
- Telecommunications systems
- Industrial control and automation equipment
- Security and surveillance systems
- Point-of-sale and business-critical computing equipment
- Sites requiring extended backup runtime during mains outages
Standards & Compliance
- AS 62040.1:2019 — applicable general and safety requirements for uninterruptible power systems; specific product certification not independently verified
- AS/NZS 3000:2018 — applicable to fixed electrical installation, isolation, earthing and cabling; installation compliance must be certified by the installer. ([eess.gov.au](https://www.eess.gov.au/wp-content/uploads/2020/07/20-006-General-guidance-Standards-for-portable-UPS-devices-1.pdf?utm_source=openai))
Environmental Benefits
- Sealed lead-acid batteries are recyclable through approved battery-recycling channels
- Ten-year design-life batteries can reduce replacement frequency and associated waste compared with shorter-life battery configurations
- Online power conditioning can help protect connected equipment and reduce premature replacement of sensitive electronic assets
Warranty Information
PSS Distributors’ standard warranty is a 2-year return-to-base warranty from the original purchase date, subject to proof of purchase and correct installation and operation. Transportation is generally excluded. Special-order or custom-built configurations may have specific warranty conditions, so confirm coverage on the quotation or invoice. ([pssdistributors.com.au](https://www.pssdistributors.com.au/ups-warranty/?utm_source=openai))
Available Now
Available through ENDURO/PSS Distributors and authorised Australian electrical and data-centre equipment distributors; supplied by quotation and subject to configured battery-cabinet availability. ([mssdatasolutions.com.au](https://www.mssdatasolutions.com.au/p/power-supplies-batteries/uninterruptible-power-supplies/line-interactive-ups/en10-120-40t-ll))
UPS Sizing Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
