10kVA 10kW Online UPS 7 Battery Banks Rack Tower Enduro

BRAND: CABAC
SKU: EN10-7-RT-LL
$19,162.00 List price: $25,549.30
Free pick up (over 25 kg or over 1 meter)
Contact us for delivery cost
30 Days Return Electricians Unlock Trade Access
Enduro 10kVA 10kW online double conversion UPS features 7 battery banks, 10 year design life batteries and rack or tower mounting. Ideal for servers.

Alternatively Known As: ENDURO EN10-7-RT-LL, 10kVA Online UPS, 10kW Server UPS, Rack/Tower UPS

Technical Specifications
  • Capacity: 10kVA / 10kW
  • UPS Topology: Online double conversion
  • Configuration: Single-phase, 1:1 input and output
  • Input Voltage: 230V ±20%
  • Input Frequency Range: 45–65Hz
  • Input Power Factor: 0.99
  • Output Voltage: 230V ±2%
  • Output Frequency: 50Hz ±0.1Hz in battery mode
  • Output Power Factor: 1.0
  • Output Waveform: Pure sinewave
  • Efficiency: 89–92% in normal mode; up to 97% in ECO mode
  • Battery Type: Sealed lead-acid, maintenance-free
  • Battery Configuration: 20 x 12V 9Ah per 10kVA UPS module, with seven extended battery modules
  • Battery Design Life: 10 years when fitted with the long-life battery option
  • Battery Recharge Time: Approximately 5 hours to 90%
  • Communications: USB and RS-232; optional SNMP and relay cards
  • Protection: Resettable circuit breaker, surge protection and emergency power-off function
  • Operating Temperature: 0–40°C
  • Operating Humidity: 0–95% non-condensing
  • Noise Level: Less than 50dB at 1m
  • Mounting: 19-inch rack or tower configuration; UPS module 5RU and each battery module 3RU
  • Compliance Marking: RCM/C-Tick listed in product documentation
  • Dimensions (H x L x W): 1134mm x 580mm x 443mm
  • Weight: 519.3 kg
Key Features
  • Provides continuous, conditioned power using online double-conversion technology
  • Suitable for sensitive servers, networking equipment, telecommunications and computer systems
  • Delivers a full 10kW of usable power at 10kVA capacity
  • Seven extended battery modules provide substantially longer runtime than the standard UPS configuration
  • Pure sinewave output supports sensitive and power-factor-corrected loads
  • Rack-mountable or convertible to tower installation
  • Interactive LCD display shows load, battery, input, output and operating status
  • Generator-compatible design
  • Emergency power-off input for rapid shutdown
  • USB and RS-232 monitoring ports with optional SNMP network management
Professional Installation Requirements
  • Installation and commissioning must be performed by a licensed electrical contractor or suitably qualified UPS technician. The unit has hardwired mains input and output connections, high-capacity battery strings and substantial installed weight. Install, protect and commission the system in accordance with the manufacturer’s instructions, applicable electrical regulations and AS/NZS 62040 requirements.
Applications
  • Server rooms and data centres
  • Network and telecommunications infrastructure
  • Industrial control and automation systems
  • Security, surveillance and access-control systems
  • Computer and point-of-sale equipment
  • Critical business and communications equipment
Standards & Compliance
  • AS/NZS 62040.1: Applicable Australian/New Zealand safety standard for uninterruptible power supply equipment; product-specific certification should be confirmed with the supplier
  • RCM/C-Tick compliance marking is listed in the product documentation
  • EN 50091-2 electromagnetic compatibility reference listed in the product documentation
Environmental Benefits
  • High-efficiency operating modes can reduce energy consumption and operating heat compared with less efficient UPS systems
  • Extended battery modules and a 10-year design-life battery option can reduce replacement frequency and electronic waste
  • Sealed lead-acid batteries are recoverable through approved battery recycling programs
  • Automatic voltage regulation and conditioned power can help reduce premature failure of connected servers and electronic equipment
Warranty Information

Standard PSS Distributors warranty is a 2-year return-to-base warranty against faulty materials and workmanship, subject to correct installation, commissioning, operating conditions and the published warranty terms. Hardwired UPS products require approved commissioning for warranty validity; batteries must be stored, charged and operated in accordance with the manufacturer’s requirements.

Available Now

Available through authorised ENDURO distributors in Australia.

UPS Sizing Calculator




This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
