10kVA 10kW Online UPS 9 Battery Banks Rack Tower Enduro
Enduro 10kVA 10kW online double conversion UPS features 9 battery banks, 10 year design life batteries and rack or tower mounting. Ideal for servers.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Enduro EN10000 Long-Run UPS, Enduro 10kVA Double-Conversion UPS, Enduro Server UPS, Enduro Rack/Tower UPS
Technical Specifications
- Rated Capacity: 10,000 VA / 10,000 W
- Topology: Online double conversion
- Battery Configuration: 48 x PSS-9LL sealed lead-acid batteries
- Battery Type: Maintenance-free sealed lead-acid
- Battery Design Life: 10 years
- Output Power Factor: 1.0
- Input: 230 V AC single phase, hardwired
- Input Frequency: 45–65 Hz
- Output Voltage: 230 V AC
- Output Waveform: Pure sine wave
- Efficiency: 89–92% in normal mode; up to 97% in ECO mode
- Communications: USB and RS-232 standard; optional SNMP and relay cards
- Display: Interactive LCD screen
- Generator Compatibility: Yes
- Mounting: Rack or tower UPS control unit; floor-standing battery bank
- Noise Level: Less than 50 dB at 1 m
- Dimensions (H x L x W): 217mm x 580mm x 443mm
- Weight: 78.3 kg
Key Features
- Provides continuous power conditioning through online double-conversion technology
- Supplies up to 10 kW of protected power for servers and other sensitive equipment
- Includes 48 long-life 9Ah batteries for extended runtime
- Rack or tower mounting flexibility for the UPS control unit
- Floor-mounted external battery bank separates high-capacity batteries from the UPS chassis
- Pure sine-wave output suitable for servers, storage and network equipment
- Generator compatible for resilient power infrastructure
- Interactive LCD provides operating, load and battery status information
- Fast-charging battery management system
- Emergency power-off function and optional network monitoring
Professional Installation Requirements
- Installation must be completed by a licensed electrician and suitably qualified UPS technician. The unit uses a hardwired 230 V AC input and requires appropriate isolation, earthing, overcurrent protection, battery-bank placement and commissioning in accordance with the installation manual and AS/NZS 3000.
Applications
- Server rooms and data centres
- Network and telecommunications equipment
- Industrial control and automation systems
- Security and camera-surveillance systems
- Point-of-sale and business-critical computing equipment
- Medical, laboratory and other sensitive electronic equipment
Standards & Compliance
- AS 62040.1:2019 applicable to UPS safety requirements
- AS/NZS 3000:2018 applicable to fixed electrical installation, wiring, isolation and earthing
- RCM/C-Tick compliance referenced for the Enduro 1–10kVA series
Environmental Benefits
- 10-year design-life batteries can reduce replacement frequency and battery waste compared with standard-life alternatives
- Sealed lead-acid batteries are suitable for established battery recycling streams when correctly recovered at end of life
- ECO mode can reduce operating energy losses where the connected load and power-quality requirements permit
- Extended service life helps reduce the material and transport impacts associated with replacement equipment
Warranty Information
PSS/Enduro warranty registration and repair/RMA support are provided, but a specific warranty duration for this 10kVA configuration was not published in the available product documentation. Coverage is understood to apply to manufacturing defects subject to the supplier’s warranty terms.
Available Now
Available through Aspen Pumps and authorised Australian electrical and UPS distributors; contact sales for current availability and delivery arrangements.
UPS Sizing Calculator
This calculator follows relevant Australian standards to ensure reliable and compliant performance. It provides an estimated recommendation based on user inputs.
Users must verify specifications before purchasing.
