11W LED Downlight with Dimmable Driver | 90° Beam Angle | IP44 Rated | Silver Finish | by atom
The 11W LED Downlight with Dimmable Driver is perfect for both residential and commercial lighting needs. Featuring a 90° beam angle and an IP44 rating for moisture resistance, this downlight ensures optimal performance in various environments. With a long LED lifetime of over 60,000 hours and a high CRI of >80, it provides excellent color rendering and energy efficiency, making it an ideal choice for recessed ceiling installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 11W LED Recessed Downlight, Dimmable LED Ceiling Light, TRI-CCT LED Downlight, Silver LED Downlight
Technical Specifications
- Total system efficiency: 114 lm/W
- IP Rating: IP44 front face only
- IC Rating: IC-4
- Body Material: Aluminium
- Diffuser Material: PMMA
- Installation Type: Recessed
- Working Temperature Range: 0 to 40 °C
- Input Frequency: 50 Hz
- Power Factor: 0.9
- Maximum Wattage: 11 W
- Input Voltage: 230Vac (216-253Vac range)
- Colour Rendering Index (CRI): >80
- Number of Lamps: 1
- LED Type: Diffused
- CCT Configuration: TRI-CCT (3000K, 4000K, 6000K)
- Macadam Steps: 4-step MacAdam Ellipse
- Beam Angle: 90°
- LED Current: 350 mA
- LED Lifetime: >60000 hrs (TM-21 report)
- Driver Type: Dimmable (Phase cut)
- Driver Included: Yes
- Driver Code: 10974
- Flex & Plug Length: 120 mm
- Wiring Type: Re-wireable Flex & Plug (2 pin)
- Driver Warranty: 3 years
- Operational Lifetime: 50000 hrs
- Dimensions (H x L x W): 60mm x 120mm x 120mm
- Weight: 0.5 kg
Key Features
- Total system efficiency of 114 lm/W
- IP44 rated front face for moisture resistance
- IC-4 rated for safe insulation coverage
- Fixed adjustability
- Powder coated aluminium body with PMMA diffuser
- Dimmable phase cut driver included
- TRI-CCT configuration with 3000K, 4000K, and 6000K colour temperatures
- High CRI >80 for accurate colour rendering
- 90° beam angle
- Long LED lifetime >60000 hours
- Power factor of 0.9
- Input voltage range 216-253Vac
- Inline switch type
- Re-wireable flex & plug with 120 mm lead
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical safety standards and optimal performance.
Applications
- Residential lighting
- Commercial lighting
- Recessed ceiling installations
- Indoor ambient and task lighting
Standards & Compliance
- AS/NZS 60598.1 – Luminaires General Requirements
- AS/NZS 60598.2.2 – Particular Requirements for Recessed Luminaires
- AS/NZS 61347.1 – Lamp Control Gear General and Safety Requirements
- AS/NZS 61347.2.13 – Particular Requirements for LED Modules
- AS CISPR 15 – Limits and Methods of Measurement of Radio Disturbance Characteristics of Electrical Lighting and Similar Equipment
Environmental Benefits
- High system efficiency reduces energy consumption
- Long LED lifetime minimizes waste and replacement frequency
- Dimmable driver allows energy savings through adjustable lighting levels
- Complies with energy savings schemes (Ipart, REES, VEU approvals)
Warranty Information
Standard warranty is 3 years return-to-base. VIP warranty offers 2 years onsite plus 3 years return-to-base (total 5 years) for registered users under specific conditions.
Available Now
The atom 11W LED Downlight with Dimmable Driver in Silver is available for immediate purchase, ideal for residential and commercial recessed lighting applications.
