11W LED Downlight with Dimmable Driver | 90° Beam Angle | Satin Chrome Finish | by atom
The 11W LED Downlight with Dimmable Driver is perfect for both residential and commercial lighting needs. Featuring a 90° beam angle and a sleek satin chrome finish, this downlight offers high efficiency with a total system efficiency of 114 lm/W. Ideal for recessed ceiling installations, it provides adjustable color temperatures and a long LED lifetime of over 60,000 hours, ensuring both style and functionality in your space.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: 11W LED Recessed Downlight, Dimmable LED Downlight, TRI-CCT LED Downlight, Satin Chrome LED Downlight
Technical Specifications
- Power: 11 W (max system wattage 12 W)
- Input Voltage: 230Vac (216-253Vac range)
- Frequency: 50 Hz
- Power Factor: 0.9
- LED Type: Diffused
- Color Rendering Index (CRI): >80
- Color Temperatures: Warm White (3000K), Cool White (4000K), Daylight (6000K)
- Lumens Output: 1150 lm (3000K), 1250 lm (4000K), 1200 lm (6000K)
- Beam Angle: 90°
- LED Current: 350 mA
- LED Lifetime: >60000 hours (TM-21 report), L90B10 at 35000 hours
- Operating Temperature Range: 0 to 40 °C
- IP Rating: IP44 front face only
- IC Rating: IC-4
- Driver Type: Dimmable phase cut, driver included, not integrated
- Driver Warranty: 3 years
- Wiring: Re-wireable flex & plug (2 pin), 120 mm lead length
- Switch Type: Inline
- Dimensions (H x L x W): 60mm x 120mm x 120mm
- Weight: 0.5 kg
Key Features
- Total system efficiency of 114 lm/W
- IP44 rated front face for moisture resistance
- IC-4 rated for safe insulation coverage
- Fixed adjustability with satin chrome powder-coated aluminium body
- Diffused LED with TRI-CCT configuration (3000K, 4000K, 6000K)
- 90° beam angle for focused lighting
- Dimmable phase cut driver included
- High color rendering index (CRI > 80)
- Long LED lifetime > 60000 hours
- Power factor of 0.9
- Inline switch type with re-wireable flex and plug
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical safety standards and optimal performance.
Applications
- Residential lighting: living rooms, kitchens, bedrooms
- Commercial lighting: offices, retail spaces, hospitality
- Recessed ceiling installations requiring adjustable color temperature and dimmable lighting
Standards & Compliance
- AS/NZS 60598.1 – Luminaires General Requirements
- AS/NZS 60598.2.2 – Particular Requirements for Recessed Luminaires
- AS/NZS 61347.1 – Lamp Control Gear General and Safety Requirements
- AS/NZS 61347.2.13 – Particular Requirements for LED Modules
- AS CISPR 15 – Limits and Methods of Measurement of Radio Disturbance Characteristics of Electrical Lighting and Similar Equipment
Environmental Benefits
- High system efficiency reduces energy consumption
- Long LED lifetime minimizes waste and replacement frequency
- Complies with energy savings schemes (Ipart, REES, VEU approvals)
Warranty Information
VIP Warranty: 2 years onsite and 3 years return-to-base (total 5 years) for registered users; standard warranty is 3 years return-to-base.
Available Now
The atom 11W LED Downlight with Dimmable Driver in Satin Chrome finish is available for immediate purchase, ideal for residential and commercial recessed lighting applications.
