16A DIN Rail Switch | Remote Control via Wiser App | Zigbee 3.0 | by Clipsal
The 16A DIN Rail Switch is designed for smart home automation, allowing remote control via the Wiser app and manual override. Perfect for residential, commercial, and industrial applications, it supports scheduling and automation scenes, ensuring energy savings and convenience. With IP20 ingress protection, this switch is ideal for indoor use, making it a reliable choice for modern electrical control.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 16A DIN Rail Switch | Remote Control via Wiser App | Zigbee 3.0 | by Clipsal
Brand: Clipsal
SKU: SCHABE7H20E000
Alternatively Known As: Clipsal Wiser DIN Rail Switch, Wiser 16A Switch, SCHABE7H20E000, Clipsal Smart Switch
Technical Specifications
- Rated Current: 16A
- Mounting: DIN rail
- Control: Remote via Wiser app, manual override
- Communication: Zigbee 3.0
- Voltage: 230V AC, 50Hz
- Operating Temperature: -10°C to +50°C
- Ingress Protection: IP20 (indoor use only)
- Dimensions (H x L x W): 90mm x 65mm x 36mm
- Weight: 0.25 kg
Key Features
- 16A DIN rail mount switch for smart automation
- Remote control via Wiser app or home automation system
- Compatible with Wiser Home and Wiser Hub
- Manual override function for local control
- Supports scheduling and automation scenes
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with Australian standards.
Applications
- Residential: Smart home automation for lighting and appliances
- Commercial: Office and building automation
- Industrial: Automated control of electrical circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables energy savings through automation and scheduling
- Reduces unnecessary power consumption by remote control
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Clipsal Wiser 16A DIN Rail Switch (WIR BAS 16Es) is available for immediate purchase. Ideal for smart home and building automation applications.
