17 Way IP2X Terminal Block | 400V 100A | Blue Cover | Rail Mount by Legrand
17 way IP2X terminal block with 400V and 100A capacity—ideal for industrial and commercial electrical panels. Built for durability with brass and zinc-plated steel, featuring a blue cover for easy identification.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 17 Way IP2X Terminal Block | 400V 100A | Blue Cover | Rail Mount by Legrand
Brand: Legrand
SKU: 04845
Alternatively Known As: Electrical Terminal Block, DIN Rail Terminal Block, Neutral Terminal Block, Phase Terminal Block, IP2X Terminal Block
Technical Specifications
- Material: Brass and zinc-plated bichromated steel
- Number of connections: 1 x 6 to 25 mm² + 16 x 1.5 to 16 mm²
- Voltage rating: 400 V~
- Current rating: 100 A max with 25 mm² input, 80 A max with 16 mm² input
- Length: 141 mm
- IP Rating: IP2X
- Mounting: Symmetrical or asymmetrical rail with universal support Cat.No 0 048 11 or on 12 x 2 flat
- Dimensions (H x L x W): 88mm x 148mm x 101mm
- Weight: 0.89 kg
Key Features
- Constructed with brass and zinc-plated bichromated steel for durability
- Blue removable cover for easy identification of neutral or phase
- IP2X rated for safety
- Can be mounted on symmetrical or asymmetrical rails with universal support
- Conforms to IEC 60998-2-1 standard
- Supports up to 100 A max at 400 V~ with 25 mm² input
- Supports up to 80 A max at 400 V~ with 16 mm² input
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper mounting on DIN rails.
Applications
- Electrical distribution and connection in industrial and commercial electrical panels
- Use with Plexo³ range, HL, and XL³ 125 enclosures
- Suitable for mounting on symmetrical or asymmetrical rails in electrical installations
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste
- Supports efficient electrical distribution, contributing to energy efficiency
Warranty Information
Standard manufacturer warranty applies. Please refer to Legrand's official warranty policy for details.
Available Now
The Legrand 17 Way IP2X Terminal Block with Blue Cover is available now for immediate purchase. Ideal for electrical distribution and connection in industrial and commercial electrical panels.
