17 Way IP2X Terminal Block | Green Cover | Rail Mounted | 100A by Legrand
17 way IP2X terminal block with green cover and rail mounting—ideal for electrical distribution systems. Built for industrial and commercial panels, with durable brass and zinc-plated steel construction.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 17 Way IP2X Terminal Block | Green Cover | Rail Mounted | 100A by Legrand
Brand: Legrand
SKU: 04835
Alternatively Known As: 17 Way Terminal Block, IP2X Terminal Block, Earth Terminal Block, DIN Rail Terminal Block
Technical Specifications
- Conforms to IEC 60998-2-1 standard
- 100 A max at 400 V~ with 25 mm² input
- 80 A max at 400 V~ with 16 mm² input
- Number of connections: 1 x 6 to 25 mm² + 16 x 1.5 to 16 mm²
- IP2X rated terminal block
- Length: 141 mm
- Mounting: Symmetrical or asymmetrical rail with universal support Cat.No 0 048 11 or on 12 x 2 flat
- Dimensions (H x L x W): 88mm x 141mm x 101mm
- Weight: 0.88 kg
Key Features
- Constructed with brass and zinc-plated bichromated steel for durability
- Green cover for easy earth supply identification
- Removable cover and compatible with extra supports
- Can be fitted with universal terminal block supports
- IP2X rated for safety
- Mountable on symmetrical or asymmetrical rails
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and safety.
Applications
- Electrical distribution systems
- Industrial and commercial electrical panels
- Use with Plexo³ range, HL, and XL³ 125 enclosures
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable materials reduce replacement frequency and waste
- Supports efficient electrical distribution reducing energy losses
Warranty Information
Standard manufacturer warranty applies; please refer to Legrand for specific warranty details.
Available Now
The Legrand 17 Way IP2X Terminal Block with Green Cover is available now for immediate purchase. Ideal for electrical distribution and industrial panel applications.
