185mm 4 Core & Earth XLPE Cable | High Current Capacity | UV & Chemical Resistant | by Electra Cables
The 185mm 4 Core & Earth XLPE Cable is designed for high current capacity and enhanced safety, making it ideal for industrial power distribution and commercial electrical installations. With its durable XLPE insulation and UV-resistant sheath, this cable ensures superior thermal performance and longevity, suitable for both underground and above ground applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 185mm 4 Core & Earth XLPE Cable | High Current Capacity | UV & Chemical Resistant | by Electra Cables
Brand: Electra Cables
SKU: XLPE41850+E-BOR
Alternatively Known As: 185mm 4C+E XLPE Cable, 185mm 4 Core and Earth Power Cable, Heavy Duty XLPE Mains Cable, 185mm Multicore XLPE Cable
Technical Specifications
- Conductor Size: 185mm²
- Number of Cores: 4 + Earth
- Insulation: XLPE (Cross-Linked Polyethylene)
- Sheath: PVC/LSZH
- Voltage Rating: 0.6/1kV
- Temperature Rating: -15°C to +90°C
- Current Rating: Up to 405A (refer to AS/NZS 3008 for installation conditions)
- Standards: AS/NZS 5000.1
- UV Resistant: Yes
- Direct Burial: Yes
- Dimensions (H x L x W): 65mm x 1000mm x 65mm
- Weight: 7.5 kg
Key Features
- 185mm² cross-sectional area for high current capacity
- 4 core plus earth configuration for enhanced safety
- XLPE (Cross-Linked Polyethylene) insulation for superior thermal and electrical performance
- Suitable for direct burial and outdoor use
- UV, moisture, and chemical resistant sheath
- Low smoke, zero halogen (LSZH) properties for improved fire safety
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations. Proper cable handling and termination tools are required.
Applications
- Industrial power distribution
- Commercial electrical installations
- Underground and above ground mains power supply
- Large infrastructure projects
- Mining and heavy engineering environments
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 5000.1 – Electric cables with extruded insulation for working voltages up to and including 0.6/1kV
Environmental Benefits
- Low smoke, zero halogen (LSZH) sheath reduces toxic emissions in case of fire
- Durable construction extends cable lifespan, reducing replacement frequency
- UV and chemical resistance minimizes environmental contamination
Warranty Information
12 months manufacturer's warranty against defects in materials and workmanship.
Available Now
The Electra 185mm 4 Core & Earth XLPE Cable is available for immediate purchase. Ideal for industrial, commercial, and infrastructure power distribution applications.
